Product Overview
Overview
The energy-efficient NGS8C2 8-Port Gigabit L2 Web-Smart Managed Network Switch features eight twisted-pair RJ45 Gigabit Ethernet ports that support auto-negotiable 10/100/1000 Mbps and auto MDI/MDIX cross-over detection functions for convenient plug-and-play capability. Two dedicated mini-GBIC SFP ports are also included for uplinking data to other switches via optical fiber or copper.
Easy-to-read LEDs indicate connection and activity status for each port. Built-in web-smart management software lets you monitor and control each connected device via secure web-based interface. Each port supports up to 2 Gbps with full duplex.
The heavy-duty metal housing mounts into 1U of an EIA-standard 19-inch rack using the included brackets and user-supplied hardware. Or attach the included rubber feet to the bottom of the unit for installation on a flat desktop surface. The five-foot input cord with NEMA 5-15P plug connects to a protected UPS, generator or mains input AC source.
Easy-to-read LEDs indicate connection and activity status for each port. Built-in web-smart management software lets you monitor and control each connected device via secure web-based interface. Each port supports up to 2 Gbps with full duplex.
The heavy-duty metal housing mounts into 1U of an EIA-standard 19-inch rack using the included brackets and user-supplied hardware. Or attach the included rubber feet to the bottom of the unit for installation on a flat desktop surface. The five-foot input cord with NEMA 5-15P plug connects to a protected UPS, generator or mains input AC source.
Features
Enterprise Managed Network Switch
- 8 twisted-pair RJ45 Gigabit Ethernet ports
- Auto-negotiable 10/100/1000 Mbps
- Automatic MDI/MDIX cross-over detection
- 20 Gbps switching capacity (2 Gbps per port with full duplex)
- Easy-to-read LEDs indicate connection and activity status for each port
- Supports 9k jumbo frames
- Supports MAC address auto-learning and auto-aging up to 8,000 addresses
- Advanced Enterprise-level and L2 management features
- Monitors and controls connected equipment via simple Web interface
- VLAN, trunking, VPN, port monitoring and other features improve network efficiency and performance
- Connect to Mini-GBIC SFP modules for uplinking to other switches via optical fiber or copper
- LEDs indicate interface traffic
- Automatically shifts unused ports to low power state without interrupting network connection
- Meets IEEE 802.3ab, 802.3i, 802.3u, 802.3x, 802.3, 802.1q, 802.1d, 802.1w and 802.3ad standards
- Fanless metal housing mounts in 1U of EIA-standard 19 in. racks
- Supports desktop installation using included rubber feet on flat surface
- 5 ft. power cord with NEMA 5-15P plug connects to compatible AC power source
Package Includes
- NGS8C2 8-Port Gigabit L2 Web-Smart Managed Network Switch
- Detachable AC power cord w/NEMA 5-15P plug, 5 ft.
- (2) Rack-mounting brackets
- (8) Screws
- (4) Rubber feet
- Owner’s manual
Specifications
OVERVIEW
| UPC Code | 037332194824 |
| Product Type | Managed Switch |
INPUT
| Electrical Consumption (Max) | 80W |
| Input Plug Features | Detachable NEMA 5-15P to C13 input plug can be replaced with a wide variety of 100 to 240V international cordsets that terminate to a C13 connector on the output side |
| Voltage Compatibility (VAC) | 100-240 |
| Input Phase | Single-Phase |
| Input Plug Type | NEMA 5-15P |
| Input Cord Length (ft.) | 5 |
USER INTERFACE, ALERTS & CONTROLS
| Switches | 1 included switch enables factory reset |
| LED Indicators | Power LED (Green for Power On); One LED per RJ45 port (Amber indicates 10/100Mbps link; Green indicates 1000Mbps link; LEDs flash to indicate port activity); Two LEDs indicate SFP connection (Green) |
PHYSICAL
| Primary Form Factor | Rackmount |
| Color | Black |
| Minimum Required Rack Depth (inches) | 8.07 |
| Shipping Dimensions (hwd / in.) | 2.90 x 9.70 x 17.20 |
| Shipping Weight (lbs.) | 6.00 |
| Unit Dimensions (hwd / in.) | 1.73 x 17.32 x 8.07 |
| Unit Weight (lbs.) | 5.4 |
| Rack Units | 1 |
ENVIRONMENTAL
| Storage Temperature Range | -40 to 158 F (-40 to 70 C) |
| Relative Humidity | 10 to 90% (Non-condensing) |
| Operating Temperature | 32 to 104 F (0 to 40 C) |
| Power Consumption (Watts) | 80 |
| Fans (Type/Quantity) | Fanless |
COMMUNICATIONS
| Network Compatibility | 1 Gbps (Gigabit) |
| Network Compatibility Details | Auto-negotiable |
| Switching Capacity | 20 Gbps |
| Switching Capacity Details | 2 Gbps per port with full duplex |
CONNECTIONS
| Ports | 10 |
| RJ45 Ports | 8 |
| RJ45 Ports Detail | 8x 10/100/1000BASE-T |
| SFP Uplink Ports | 2 |
| SFP Uplink Ports Detail | 2x Mini-GBIC SFP Uplinks |
| PoE Supported Ports | 0 |
| Network Switch Ports | (8) 10/100/1000 (RJ45); (2) Dedicated SFP |
FEATURES & SPECIFICATIONS
| MAC Addresses | 8000 |
| Jumbo Frames | 9000 |
| OSI Layer | Layer 2 |
| Console Port | No |
| MAC Auto Learning | Yes |
| RMON | Yes |
| SNMP | Yes |
| Storm Control | Yes |
| DHCP Snooping | Yes |
| Auto MDI/MDIX Crossover Detection | Yes |
STANDARDS & COMPLIANCE
| Certifications | Compliant standards: IEEE 802.3ab (1000BASE-T GIGABIT ETHERNET), IEEE 802.3i (10BASE-T ETHERNET), IEEE 802.3u (100BASE-T ETHERNET), IEEE 802.3x (FULL DUPLEX/FLOW CONTROL), IEEE 802.3 (NWAY AUTO-NEGOTIATION), 802.1q(TAGGED VLAN), 802.1d(STP), 802.1w (RSTP), 802.1p (QUALITY OF SERVICE) |
| Approvals | Tested to: UL 60950-1:2007 (2nd Ed); CAN/CSA C22.2 NO. 60950-1-07 2nd Edition |
WARRANTY
| Product Warranty Period (Worldwide) | 5-year limited warranty |
