Tripp-Lite P019-008-C15RA 8Ft Heavy Duty Power Extension Cord

$24.99
SKU:
P019-008-C15RA
Shipping:
Calculated at Checkout
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description



Features

IEC C15 Power Cord for Network Devices That Require a Heavy-Gauge Connection
This IEC C15 power cable features 14 AWG wire suitable for high power connections, making it reliable for large server applications that require a higher-rated, heavier-gauge cable. The C15 connector is designed for higher-temperature devices, such as electric kettles, PoE (Power over Ethernet) switches with high-wattage power supplies, and similar network components. This cord can also replace or upgrade the standard power cord provided by the device's manufacturer. The 8-ft. (2.43 m) length allows you flexibility in placing equipment with respect to the power outlet.
Right-Angle C15 Plug Makes Connecting in Tight Spaces Easier
The C15 right-angle power cable is easier to install in confined spaces, such as the back of a rack enclosure cabinet. When plugged in, the right-angled C15 plug guides the cable parallel to your peripheral, allowing you to push the device up against a wall or hide it behind a desk to maximize space.

Package Includes

  • P019-008-C15RA 5-15P to Right-Angle C15 Power Cord, 8-ft. (2.43 m), Black
RoHS compliant

Specifications

OVERVIEW
UPC Code 037332202413
Device Compatibility Computer; Server; Network Switch; UPS; PDU
Country/Region North America
INPUT
Maximum Input Amps 15
Voltage Compatibility (VAC) 125
PHYSICAL
Plug Color Black
Cable Jacket Color Black
Cable Jacket Material PVC
Cable Jacket Rating VW-1
Power Cord Jacket Type SJT
Cable Outer Diameter (OD) 9.20mm
Number of Conductors 3
Wire Gauge (AWG) 14
Cable Length (ft.) 8
Shipping Dimensions (hwd / in.) 0.50 x 11.80 x 14.00
Shipping Weight (lbs.) 1.00
ENVIRONMENTAL
Operating Temperature Range -4 F TO 140 F (-20 C TO 60 C)
Storage Temperature Range -4 F TO 140 F (-20 C TO 60 C)
Operating Humidity Range 10 TO 65% RH
Storage Humidity Range 10 TO 65% RH
CONNECTIONS
Side A - Connector 1 NEMA 5-15P
Side B - Connector 1 IEC-320-C15 – RIGHT ANGLE
FEATURES & SPECIFICATIONS
Locking Plug No
Angled Plug Yes
STANDARDS & COMPLIANCE
Certifications UL/cUL
Approvals UL/CSA
WARRANTY
Product Warranty Period (Worldwide) Lifetime limited warranty
