Description
Features
- Compact and low-profile for minimal obstruction of audience sightlines
- 50° x 90° nominal coverage
- Bi-amplified or full-range passive operation
- Differential Drive® woofer with neodymium magnet for high power capacity and very light weight
- 4" (voice coil) diameter compression driver with neodymium magnet
Specifications
| Power Rating | 800 W / 1600 W / 3200W |
| Frequency Response (-10dB) | 60 Hz - 20 kHz |
| Dimensions (H x W x D) | 629 mm x 432 mm x 324 mm (375 mm stage height) 24.75 in x 17 in x 12.75 in (14.75" stage height) |
| Coverage Pattern (-6 dB) | 50° x 90° nominal |
| Crossover Modes | Passive / Bi-amp |
| Crossover Frequency | 1.1 kHz |
| Maximum SPL (1m) | 127 dB SPL continuous (133 dB SPL peak) |
| Sensitivity | 98 dB SPL |
| LF Driver | 1 x JBL 2265H 380 mm (15 in) Differential Drive® woofer 8 Ohms |
| HF Driver | 1 x JBL 2453H-SL, 38 mm (1.5 in) exit compression driver, 100 mm (4 in) voice coil and neodymium magnet |
| Nominal Impedance | 8 ohms |
| Active Tunings | Tunings available at www.jblpro.com |
| Enclosure | Symmetrical stage monitor, 15/18 mm, plywood |
| Finish | Black DuraFlex™ finish |
| Grille | Powder coated, black, 16 gauge perforated steel with acoustically transparent black screen backing |
| Inputs | Neutrik® Speakon® NL-4 (x2), one on each end |
| Net Weight (each) | 21 kg (46.0 lb) |
| Outputs | 1 x XLR |
Accessories
VRX915M-CVR-CXD | Deluxe Convertible Cover for VRX915M
Deluxe convertible padded cover for VRX915M. Water Resistant Black Nylon, 10mm padding, Allows Full Functionality Of Speaker While Inside Protective Cover. Full Access to Grille, Inputs, & Carry Handles.
