Description
Rack-Mountable Fan Assemblies, 315CFM 115V, Lt Gray, Steel
- Slim 1.75 inch (44 mm) Panel Height
- 19-inch rack mountable
- Field adjustable fan strips to optimize air flow
- Easy access to fan tray from front and back
- Simplified installation without the need for side access
- Support bracket
- Exhaust Guard
- 6-inch Power Cord AC trays, Terminal block on DC trays
- Permanently lubricated ball bearing motors
- 100% functionally tested
PRODUCT ATTRIBUTES
- Height: 1.75 in / 44 mm
- Width: 19 in / 483 mm
- Depth: 8 in / 203 mm
- Material: Mild Steel
- Finish: Powder Coated
- Color: Light Gray
- Color Code: RAL 7035
- Thickness: 16 ga / 1.52 mm
- Fan Quantity: 3
- Weight: 11 lb
DRAWINGS AND DOCUMENT DOWNLOADS
3D Step
Approval Agency Certificate
Data Sheet
Installation Manual / Instruction Sheet
Declarations
ADDITIONAL PRODUCT DETAILS
Fan trays are a versatile solution to cooling card cages and racks. Redundant cooling with optional failure detection makes this air mover the obvious choice for sensitive equipment. Minimal rack space and repositionable fans are suited to today's smaller enclosures.
BULLETIN NUMBER
MCLO
