Camden Controls CX-93M-12LS 1200 Lb. Shear Lock

Write a Review
$370.00
SKU:
CX-93M-12LS
Shipping:
Calculated at Checkout

Product Overview

OVERVIEW:

Camden CX-93M Series shear locks are designed for swinging doors, where the lock can be mortised into the door and frame. The new CX-93M-12LS has a rugged and compact design, 1,200 Lb. holding force, door monitor contact, and selectable 3 to 12 second timer.

FEATURES

  • CX-93M-26LS: 3,300 Lb. (1,497 Kg.) holding force
    CX-93M-12LS: 1,200 Lb. (545 Kg.) holding force
  • Compatible with all access/egress systems
  • Field selectable 12/24 VDC operation
  • Built-in door monitor sensor and relay output,
    CX-93M-26LS: 1 Amp. @ 30 VDC
    CX-93M-12LS: 0.5 Amp. @ 28 VDC
  • CX-93M-12LS: Selectable 3, 6, 9 and 12 second timer
  • Lifetime warranty

SPECIFICATIONS:

  • Voltage: 12/24 VDC
  • Current Draw:
    • CX-93M-26LS:
      • 600 mA @ 24 VDC
      • 300 mA @ 12 VDC
  • Temp Range: 14°F to 122°F (-10°C to 50°C)
  • Contact Rating:
    • Bond Sensor: 0.5 A @ 28 VDC
  • Time Delay: Selectable 3, 6, 9 & 12 Seconds
