Sprecher + Schuh's L11 series of fused and non-fused disconnect switches comply with UL98 service entrance requirements and are NFPA 79 compliant. This family of rod-operated switches is suitable for applications that require small panel space and superior short circuit protection.
FEATURES
- Fused Disconnects
- High short circuit current rating
- Touch-safe design
- Each phase is electrically isolated – minimizing possible phase to phase short
- Double-break switching for full fuse line and load side isolation when switch is OFF
- RoHS compliant
- Non-Fused Disconnects
- Compact footprint for both UL and IEC switch bodies
- Suitable for severe utilization categories (AC-22 & AC-23)
- Fast opening and closing, independent from operator allows the switch to close on short circuit and also to operate high inductive load
- Features of both
- Flange Mounted
- Rotary handle
- Rod/Shaft actuation
- Withstand ratings to 100 kA
- NFPA 79 Compliant
- At motor disconnect options available
SPECIFICATIONS
- Fused
- Range from 30A up to 800 A for UL
- Class J and L fuses
- Suitable as at-motor disconnecting means (UL 508)
- Suitable as service entrance disconnecting means (UL 98)
- Non-fused
- Range from 30A up to 1200 A for UL
- Suitable as at-motor disconnecting means (UL 508)
- Suitable as service entrance disconnecting means (UL 98)
