Product Overview

Extra-Deep Pushbutton Enclosure Type 4, 1PBx30.5mm 4x4x4.75in, Gray, Steel

Seams continuously welded and ground smooth
Captivated stainless steel cover screws thread into sealed wells
Grounding stud on body
Bonding provision on cover
High-performance polyurethane gasket
Factory stamped 4-way pushbutton holes
Enclosures 6.00 x 4.00 x 5.00 in. (152 x 102 x 127 mm) and larger have internal detachable hinge to hold cover open during wiring, yet permit immediate removal
30.5-mm or 22.5-mm size holes
External wall-mounting brackets

PRODUCT ATTRIBUTES

Height: 4 in / 102 mm
Width: 4 in / 102 mm
Depth: 4.75 in / 121 mm
Protection Rating: NEMA Type 12; NEMA Type 4; IP66
Material: Mild Steel
Hole Size: 30.5 mm
Hole Quantity: 1
Mounting: 4.50 x 3.12 in / 114 x 79 mm
Overall Dimensions: 5.00 x 4.22 in / 127 x 107 mm
Color: Gray
Color Code: ANSI 61
Finish: Powder Coated
Thickness: 16 ga / 1.52 mm
Weight: 2.3 lb

DRAWINGS AND DOCUMENT DOWNLOADS

ADDITIONAL PRODUCT DETAILS

Extra-Deep Pushbutton Enclosures, designed to hold 30.5-mm and 22.5-mm pushbuttons and switches, feature stainless steel screws and a high-performance polyurethane gasket to meet Type 4 environmental protection rating. The added depth accommodates additional pushbutton contact blocks.

BULLETIN NUMBER

PB1
