Product Overview
11253909 – 16 AWG 2C STR, GRAY, 5 X 50 FT. COILS
This Genesis® cable features 2 stranded 16 AWG copper conductors and a general purpose rating. Choose this cable for a dependable connection for security, controls, audio, and other low-voltage applications.
| Cable Rating | General Purpose |
|---|---|
| Cable Listing | CL2, CM, Sunlight Resistant |
| Wire Gauge (AWG) | 16 |
| Solid or Stranded | Stranded |
| Number of Strands | 26 |
| Conductor Material | Bare Copper |
| Number of Conductors | 2 |
| Conductor Insulation Material | Polypropylene |
| Insulation Colors | Black, Red |
| Shielding | No |
| Rip Cord | Yes |
| Jacket Material | PVC |
| Nominal Outer Diameter | 0.172 in. |
| Rated Voltage (Max) | 300 Volts |
| DC Resistance (Max) | 4.19 Ohms / 1000 ft. at 20 °C |
| Capacitance (Nominal) | 23.2 pF / ft. |
| Impedance (Nominal) | 66 Ohms |
| Velocity of Propagation | 67% |
| Temperature Rating (Max) | 60 °C |
| Temperature Rating (Min) | -20 °C |
| Product Length | 250 ft |
| Length Per Unit | 50 ft. |
| Package Quantity | 5 |
| Cable Packaging | Coil |
| Package Length | 10 in |
| Package Width | 10 in |
| Package Height | 8 in |
| Product Weight | 5.9 lb |
