Product Overview
DESCRIPTION
RS232 to RS485/RS422 Interface Converter DB9 -M /DB9-F (Ext. Powered) w/Opto- Isolation
L-com's SC-232-D RS-232 interface converter features optical isolation to protect your valuable communications equipment from damaging ground loops. Additional features include Send Data Control (SDC) which automatically enables the RS-485 driver when data is present on the RS-232 side, 2,500 Volt isolation and 1,500 Watt surge protection. Includes DB9 female to screw terminal block adapter. SC-5VDC-PWR available (sold separately) Order online today!
FEATURES
- Used to convert RS-232 to RS-485/RS-422
- 2,500V Opto-Isolation
- External 5V DC power supply available, required for the RS-485/422 side only (sold separately)
- Automatic Send Data Control, no software drivers needed
- Operating temp: -40C to +85C
APPLICATION
- SCADA
- RS-232
- RS-485
- Industrial networking
- Serial communications
DESCRIPTION
RS232 to RS485/RS422 Interface Converter DB9 -M /DB9-F (Ext. Powered) w/Opto- Isolation
L-com's SC-232-D RS-232 interface converter features optical isolation to protect your valuable communications equipment from damaging ground loops. Additional features include Send Data Control (SDC) which automatically enables the RS-485 driver when data is present on the RS-232 side, 2,500 Volt isolation and 1,500 Watt surge protection. Includes DB9 female to screw terminal block adapter. SC-5VDC-PWR available (sold separately) Order online today!
FEATURES
- Used to convert RS-232 to RS-485/RS-422
- 2,500V Opto-Isolation
- External 5V DC power supply available, required for the RS-485/422 side only (sold separately)
- Automatic Send Data Control, no software drivers needed
- Operating temp: -40C to +85C
APPLICATION
- SCADA
- RS-232
- RS-485
- Industrial networking
- Serial communications
