Product Overview

Elbow 90-Degree Feed-Through Wireway, 6.00x6.00, Gray, Mild Steel

Feed-Through 90-Degree Elbows are used for continuous runs with 90-degree turns
Connects to other wireway sections and fittings and protects wires and cables against dust in a broad range of industrial applications

PRODUCT ATTRIBUTES

Type: Elbow
Height: 6 in / 152 mm
Width: 6 in / 152 mm
Protection Rating: NEMA Type 12; IP54
Material: Mild Steel
Color: Gray
Color Code: ANSI 61
Finish: Powder Coated
Thickness: 14 ga / 1.9 mm
Weight: 7.9 lb

DRAWINGS AND DOCUMENT DOWNLOADS

ADDITIONAL PRODUCT DETAILS

Feed-Through 90-Degree Elbows are used for continuous runs with 90-degree turns. Connects to other wireway sections and fittings and protects wires and cables against dust in a broad range of industrial applications.

All dimensions are to outside surfaces. Allow .12 in. (3 mm) additional for gasket at joints. Dimension K is from intersection of center lines.

BULLETIN NUMBER

F20
