Hoffman F66WE45 45-Degree Elbow

Hoffman F66WE45 45-Degree Elbow

$245.00
SKU:
F66WE45
Shipping:
Calculated at Checkout
Product Type:
45 Degree Elbows
Material:
Steel
Nema Product Type:
Nema Type 12
Height:
6
Width:
6
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Manufacturer Information

Hoffman has a $50 fee on all air orders. This fee will be incorporated into the shipping price. Hoffman orders of $7500 or more ship for free.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Elbow 45-Degree Feed-Through, 6.00x6.00, Gray, Steel

  • Feed-Through 45-Degree Elbows are used for continuous runs with 45-degree turns
  • Connects to other wireway sections and fittings and protects wires and cables against dust in a broad range of industrial applications

PRODUCT ATTRIBUTES

  • Type: Elbow
  • Height: 6 in / 152 mm
  • Width: 6 in / 152 mm
  • Protection Rating: NEMA Type 12; IP54
  • Material: Mild Steel
  • Color: Gray
  • Color Code: ANSI 61
  • Finish: Powder Coated
  • Thickness: 14 ga / 1.9 mm
  • Weight: 5.1 lb

ADDITIONAL PRODUCT DETAILS

Feed-Through 45-Degree Elbows are used for continuous runs with 45-degree turns. Connects to other wireway sections and fittings and protects wires and cables against dust in a broad range of industrial applications.

All dimensions are to outside surfaces. Allow .12 in. (3 mm) additional for gasket at joints. Dimension J is from intersection of center lines.

BULLETIN NUMBER

F20
