Description
FEATURES
- Supports 32 CH 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P /1280×1024/960P/720P/960H/D1/CIFIP input
- H.265S/ H.265+/ H.265/ H.264 coding
- Intuitive and user-friendly Graphic User Interface ( GUI ), Windows style operation by mouse
- Multi-mode recording: manual / timed / motion / sensor / POS / AI recording
- Playback : 16 CH simultaneous playback
- Search : time slice, time, event, tag and smart search
- Supports face detection and comparison
- Supports multiple VCA (Video Content Analytics) events, such as object abandoned/missing, region intrusion, tripwire, video exception, etc.
- Supports POS information overlay on live view and playback
- Supports RAID0, RAID1, RAID5, RAID6, RAID10
- Express and flexible backup via USB, network and so on
- Pentaplex : preview, record, playback, backup and remote access
- DHCP, DDNS, PPPoE network protocol
- Remote control via Web Client or CMS : preview, playback, backup, PTZ and configuration
- Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
- Multi-user online simultaneously
- Authorization management, log view and device status view
- 4K output, true high resolution display
- Supports PTZ preset and auto cruise, up to 255 presets and 8 cruises
- Supports NAT function and QRCode scanning by mobile phones
- Powerful mobile surveillance by smart phones with iOS and Andriod OS
SPECIFICATIONS
System:
- OS: Embedded Linux
Video:
- Network Input: 32 CH IPC input
- Incoming/Outgoing Bandwidth: 256Mbps / 256Mbps
- Network Input Resolution: 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/ 960P/720P/960H/D1/CIF
- Output:
- HDMI1 : 3840×2160@60fps/3840×2160@30fps/ 1920×1080/1280×1024/1024×768
- HDMI2: 1920×1080/1280×1024/1024×768
- VGA × 1 : 1920×1080/1280×1024/1024×768
- Compression: H.265S/ H.265+/ H.265/ H.264
- Multi-screen Display: 1/4/6/8/9/13/16/25/32/36
Audio:
- Network Input: 32 CH IPC audio input
- 2-way Audio: RCA × 1
- Local Output: RCA × 1
- Compression: G.711(A/U)
Record:
- Record Stream: Dual stream recording
- Resolution:
- 12MP@20fps; 8MP/ 6MP/5MP/4MP/3MP/
- 1080P/1280×1024/960P/ 720P/960H/ D1/CIF@30fps(NTSC)/25fps(PAL)
Playback:
- Simultaneous Playback: Max 16 CH
- Search: Time slice / time / event / tag / smart search
- Smart Search: Highlighted color to display the camera record in a certain period of time, different colors refers to different record events
- Function: Play, pause, FF, FB, digital zoom, etc
Decoding Capability:
- Live View/ Playback: 1CH 12MP/4CH 5MP/9CH 720P/16CH D1
Alarm:
- Mode: Manual, sensor, motion, exception, smart events
- Input: 8 CH local alarm input; supports IPC alarm input
- Output: 4 CH
- Triggering: Record, snapshot, buzzer, preset, e-mail, etc.
Face:
- Channel: 32 CH
- Face Picture Database: 32 libraries 5000 Face Pictures
- Computing Capability: 180 pictures / minute
- Face Picture Search: Search by picture is supported
- Database Management: Add, modify, delete and search face pictures
- Face Picture Adding: Add face pictures through APP, WEB and external import
- Face Picture Comparison: Support allow list, block list and stranger match alarm
- Track: Track display on a map
- Statistic Graph of Face Information: Bar graph
- Statistic Mode of Face Information: Statistics by day, week, month, quarter as well as customized time period
Video Structure Analysis:
- Human/Vehicle Classification: Yes
Other Functions:
- Fisheye: Supports fisheye dewarping via Web Client and mobile APP
- Plate Recognition: Yes
Network:
- Interface: RJ45 10/100/1000 Mbps × 2
- Protocol: TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, RTSP, HTTP, HTTPs, 802.1x, SNMP, ONVIF, etc.
- Client Connection: Max.20 users access
Mobile Device:
- OS: iOS, Andriod
Storage:
- HDD Interface: SATA×8, up to 8TB per HDD; e-SATA×2
- RAID: RAID0, RAID1, RAID5, RAID6, RAID10
Backup:
- Local Backup: U disk, USB mobile HDD
- Network Backup: Yes
Port:
- USB: USB2.0×2, USB3.0×1
- RS 485: Yes (full-duplex); connect to PTZ or keyboard
- Remote Controller: Yes
Others:
- Warranty: 3 Years
- Power Supply:ATX 250W
- Consumption: ≤ 30W (without HDD)
- Dimensions (mm): 445×436×90 (W×D×H)
- Working Environment: -10 ~ 50 °C, 10% ~ 90% humidity
- Certificate: CE, FCC
- Environmental Protection: Directive EU RoHS, REACH and WEEE
