Product Overview
Overview
Whether you’re at home or in the office, Tripp Lite’s U280-007-CQC-ST 7-Port USB Charging Station provides enough ports and power to keep your devices at 100% capacity. No more peering behind furniture to find an available outlet or unplugging one device to charge another. You can charge up to seven tablets, smartphones and other devices at the same time. The U280-007-CQC-ST doesn’t require a computer, so you can take it anywhere AC power is available.
The U280-007-CQC-ST features five USB-A ports, each capable of delivering up to 5V, 2.4A, which is enough for charging even battery-intensive devices like the Apple® iPad®. A USB-C port provides up to 5V, 3A for more powerful devices. Plus, a Quick Charge 3.0 port is capable of rapid-charging compliant devices up to four times faster than normal USB charging.
In addition, this charging station doubles as a storage unit by providing space to neatly organize cabling while your devices charge. When not in use, cables can be stored in the compartment and kept out of the way. The included adjustable brackets accommodate the number and size of the devices being charged.
To charge your USB devices, simply connect the five-foot power cord’s NEMA 1-15P plug to an AC power outlet, and connect your devices to the available USB ports. The unit protects against overheating, overcurrent and overcharging—in fact, it stops charging as soon as your devices’ batteries are at full capacity. Also, each USB-A port complies with USB Battery Charging (BC) specification v1.2. The brackets and power supply store conveniently in the charging station when not in use.
Features
Charges Up to 7 Devices at the Same Time
- Recommended for charging tablets, smartphones and other devices at home or work
- Functions anywhere AC power is available—no computer required
Provides Plenty of Juice for Charging
- Quick Charge 3.0 Class A 5/9/12V technology
- QC 3.0-compliant devices charge up to 4x faster than conventional USB charging
- Delivers up to 5V, 2.4A per USB-A port—enough for charging battery-intensive devices like the Apple iPad
- USB-C port provides up to 5V, 3A of charging power
- Protects against overheating, overcurrent and overcharging
- Complies with USB Battery Charging (BC) specification v1.2
Efficiently Stores Your Cables / Devices Too
- 9 adjustable brackets provide space to neatly organize devices as they charge
- Convenient storage compartment lets you neatly organize your cabling while your devices charge
- When not in use, cables can be stored in the compartment and kept out of the way
Easy to Use
- External dual-voltage power supply with C8 power inlet and detachable C7 to 1-15P 5 ft. cord
- No computer required
Package Includes
- U280-007-CQC-ST 7-Port USB Charging Station
- (9) Storage brackets
- External power supply (Input: 100–240V, 50/60 Hz, 1.5A; Output: 15V, 4A)
- C7 to NEMA 1-15P power cord, 5 ft.
- Quick Start Guide
Specifications
OVERVIEW
| UPC Code | 037332199577 |
| Product Type | Charging Station |
| Charging Form Factor | Charging Hub |
| Device Compatibility | Phone; Tablet; Amazon Kindle |
INPUT
| Nominal Input Voltage(s) Supported | 120V AC; 230V AC |
| Voltage Compatibility (VAC) | 100; 110; 120; 125; 127; 200; 208; 220; 230; 240 |
| Input Frequency | 50/60Hz |
| Input Plug Type | NEMA 1-15P (NON-POLARIZED) |
| Input Current | 1.5A |
OUTPUT
| Output Capacity | 15V 4A |
| Overload Protection | Yes |
BATTERY
| Battery Charging (5V/1.5A Port) | Yes |
POWER
| AC Adapter | Input: 100-240V, 50/60Hz, 1.5A; Output: 15V, 4A |
| External Power Supply Input Specs (V / Hz / A) | 100-240V, 50/60Hz, 1.5A |
| External Power Supply Output Specs (V / A) | 15V / 4A |
| External Power Supply Cord Length (ft.) | 3 |
| External Power Supply Cord Length (m.) | 1 |
| DC Barrel Plug | OD: 5.5 x 2.5 x 10mm, Positive Pin, Negative Sleeve |
| Power Consumption (Watts) | 15.6 |
| External Power Supply Plug(s) | NEMA 1-15P North America |
| USB Power Delivery (PD) Charging Support | Yes |
| USB Power Delivery (PD) Charging Specification | 2.0 |
| Power Consumption Detail | 15.6W (Operating) 0.07W (Standby) |
USER INTERFACE, ALERTS & CONTROLS
| LED Indicators | Blue (Power) |
CHARGING
| Number of Charging Ports | 7 |
| Total Charging Amps | 9.1A |
| Total Charging Watts | 60 |
| Charging Method | USB |
| Charging Port Type | (6) USB A (FEMALE); USB C (FEMALE) |
| Charging Ports Details | USB-A: 5V/2.4A USB-A QC: 3.6V~6.5V/3A, 6.5V~9V/2A, 9V~12V/1.5A USB-C: 5V/3A |
| Charging Ports / Amps | (5) 2.4A; (1) 3A; (1) 3A / 2A / 1.5A |
| Overcharge Protection | Yes |
| Charging Method Detail | Quick Charge 3.0; 5V - 1.5A (7W) |
PHYSICAL
| Material of Construction | Polycarbonate |
| Color | Black |
| Shipping Dimensions (hwd / in.) | 2.80 x 6.30 x 10.20 |
| Shipping Weight (lbs.) | 2.00 |
| Unit Dimensions (hwd / in.) | 0.79 x 6.6 x 4.9 |
| Unit Packaging Type | Box |
| Unit Weight (lbs.) | 1.4 |
ENVIRONMENTAL
| Operating Temperature Range | 41 to 95 F (5 to 35 C) |
| Storage Temperature Range | -4 to 122 F (-20 to 50 C) |
| Relative Humidity | 20% to 80% RH, Non-Condensing |
CONNECTIONS
| Number of Ports | 7 |
| Side A - Connector 1 | NEMA 1-15P (NON-POLARIZED) |
| Side B - Connector 1 | (6) USB A (FEMALE) |
| Side B - Connector 2 | USB C (FEMALE) |
FEATURES & SPECIFICATIONS
| Over Current Protection | Yes |
| Quick Charge Compliant | 3.0 |
| Overcurrent Protection | Yes |
| Overvoltage Protection | Yes |
| GaN Technology | No |
STANDARDS & COMPLIANCE
| Certifications | FCC, REACH, RoHS |
| External Power Supply Certifications | CCC; FCC; GS; PSE; RoHS; TUV; UL; cUL |
WARRANTY
| Product Warranty Period (Worldwide) | 2-year limited warranty |
