Product Overview
Features
- 16/20A single phase 208/230V Local Metered Power Distribution Unit / PDU (Agency de-rated to 16A continuous)
- Built-in 2 digit visual meter continuously reports PDU load level in amps
- C20 inlet with C20 input cable and L6-20P adapter; 12-ft. (3.66 m) line cord
- 1U horizontal rackmount format installs in one rack space
- 10 total outlets (8 C13 / 2 C19)
- Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats
- Mounting ears are reversible for front or rear facing rackmount installation
- Optional PDUSIDEBRKT enables 0U vertical rackmount in compatible racks
Back panel grounding lug - Federal Trade Agreements Act / TAA Compliant for GSA Schedule purchases
Package Includes
- Rackmount PDU
- C19 to L6-20P plug adapter
- Rack mounting brackets
Specifications
OVERVIEW
| UPC Code | 037332159014 |
| PDU Type | Local Metered |
INPUT
| PDU Input Voltage | 208; 230 |
| Recommended Electrical Service | Single-phase 16/20A 230/208V service |
| Maximum Input Amps | 16 |
| Maximum Input Amps Details | Agency de-rated to 16A continuous |
| Input Connection Type | C20 inlet |
| PDU Plug Type | NEMA L6-20P; IEC-320 C20 |
| Input Phase | Single-Phase |
| Input Cord Details | Includes 12 ft. / 3.6m C19 to C20 power cable and L6-20P plug adapter |
| Input Cord Length (ft.) | 12 |
OUTPUT
| Output Capacity Details | 3.68kW (230V), 3.33kW (208V) / 16A total capacity; 16A max per C19 outlet; 12A (10A CE) max per C13 outlet |
| Frequency Compatibility | 50 / 60 Hz |
| Output Receptacles | (8) C13; (2) C19 |
| Output Nominal Voltage | 208/230V |
USER INTERFACE, ALERTS & CONTROLS
| Front Panel LCD Display | Digital display reports total PDU output current in amps |
PHYSICAL
| Material of Construction | Metal |
| Form Factors Supported | 1U rackmount. Includes mounting accessories for 2-4 post racks |
| Minimum Required Rack Depth (inches) | 9.5 |
| PDU Form Factor | Horizontal (1U) |
| Shipping Dimensions (hwd / in.) | 2.20 x 11.60 x 20.40 |
| Shipping Weight (lbs.) | 7.50 |
| Unit Dimensions (hwd / in.) | 1.75 x 17.5 x 6.5 |
| Unit Weight (lbs.) | 6.80 |
ENVIRONMENTAL
| Operating Temperature Range | 0C ~ 40C (32F ~ 104F) |
| Storage Temperature Range | -30°C to +50°C (-22°F to +122°F) |
| Relative Humidity | 5-95% non-condensing |
| Operating Elevation (ft.) | 0-10,000 |
| Operating Elevation (m) | 0-3000 |
FEATURES & SPECIFICATIONS
| TVSS Grounding | Rear grounding lug |
STANDARDS & COMPLIANCE
| Certifications | Tested to IEC62368-1 (CE/EU), Class A (Emissions), NOM (Mexico), RETIE (Columbia), EAC/PCT (Russia), GOST, RoHS compliant, TAA Compliant |
| Certification Details | Series Number(s) AGPD7985 |
WARRANTY
| Product Warranty Period (Worldwide) | 2-year limited warranty |
