Product Overview
Overview
Tripp Lite B119-4X4 is a 4x4 HDMI Matrix Switch that routes high definition video from any four HDMI sources to any four HDMI displays. It supports video resolutions up to 1920 x 1200 (1080p) @ 60Hz. The 4x4 Matrix eliminates the need to disconnect and reconnect HDMI sources. It works with any HDMI source that connects to an HDMI display, and each source is accessible at all times by any display by selecting it with an IR remote, or using the RS232 port to switch the unit.
Features
- Share multiple HDMI sources between multiple monitors
- Allows any input to be routed to any output; or the same input to be routed to multiple outputs
- Switch between inputs via pushbuttons, remote control, or RS-232 serial
- Monitors can be located up to 25 ft. from the switch
- Supports video resolutions up to 1920 x 1200 (1080p) @ 60Hz
- HDCP and EDID compatible
- Mounting hardware included
- Plug-and-play; No software or drivers required
- Compatible with all operating systems
- Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
Package Includes
- B119-4X4 Local Transmitter Unit
- External Power Supply with NEMA 1-15P Plug (Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 3A)
- 3.5 mm to DB9 Adapter Cable
- IR Extension Cable, 5 ft.
- Mounting Hardware
- Remote Control
- Owner’s Manual
Specifications
OVERVIEW
| UPC Code | 037332180179 |
| Technology | HDMI; IR |
VIDEO
| Supported Resolutions | 1920x1080 (1080p) |
POWER
| AC Adapter | Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 3A |
PHYSICAL
| Color | Black |
| Included Mounting Accessories | Yes |
| Rackmountable | No |
| Shipping Dimensions (hwd / in.) | 2.10 x 6.30 x 13.70 |
| Shipping Weight (lbs.) | 2.30 |
| Unit Dimensions (hwd / in.) | 1.2 x 9.2 x 3.9 |
| Unit Weight (lbs.) | 1.45 |
COMMUNICATIONS
| Port Control | Push Buttons |
| Signal Range (ft.) | 60 |
| IP Remote Access | Yes |
| EDID Compatible | Yes |
| RS-232 Serial Extension Support | Yes |
CONNECTIONS
| Number of Ports | 4 |
| Side A - Connector 1 | (4) HDMI (FEMALE) |
| Side B - Connector 1 | (4) HDMI (FEMALE) |
WARRANTY
| Product Warranty Period (Worldwide) |
3-year limited warranty |
