Macromatic TR-6182U

$111.24
SKU:
TR-6182U
Shipping:
Calculated at Checkout

Product Overview

DESCRIPTION

Watchdog, 12-125V DC 24-240VAC, 10 amp DPDT, 50ms-100 Hrs, Plug-in

Upon application of input voltage, the time delay relay is ready to accept a trigger. When the trigger is applied, the output is energized and the time delay (t) begins. At the end of the time delay (t), the output is de-energized unless the trigger is removed and re-applied prior to time out (before time delay (t) elapses). Continuous cycling of the trigger at a rate faster than the time delay (t) will cause the output to remain energized indefinitely.

FEATURES

RESOURCES

Spec Sheet

DESCRIPTION

Watchdog, 12-125V DC 24-240VAC, 10 amp DPDT, 50ms-100 Hrs, Plug-in

Upon application of input voltage, the time delay relay is ready to accept a trigger. When the trigger is applied, the output is energized and the time delay (t) begins. At the end of the time delay (t), the output is de-energized unless the trigger is removed and re-applied prior to time out (before time delay (t) elapses). Continuous cycling of the trigger at a rate faster than the time delay (t) will cause the output to remain energized indefinitely.

FEATURES

RESOURCES

Spec Sheet
