Description
Panel-Mount Fan Speed Controls, 120v 50/60Hz, Steel
- Automatically adjusts fan speed depending on remote temperature sensor input
- Temperature set point is field adjustable; preset at 35 C (95 F)
- Idle speed and temperature slope are field-adjustable
- Push-to-reset thermal circuit breaker inside control housing
- Compact polycarbonate control housing can be mounted in any position
- NEMA 5-15R outlet provides power to fan
- Six-foot (1.83-m) power cord plugs into standard 120 V, 50 or 60 Hz outlet
- Remote temperature sensor with 10-ft. (3.05-m) lead mounts in airflow
- Mounting brackets included
PRODUCT ATTRIBUTES
- Height: 2.16 in / 54.864 mm / 55 mm
- Width: 3.15 in / 80.01 mm / 80 mm
- Depth: 4.72 in / 119.888 mm / 120 mm
- Material: Polycarbonate
- Voltage AC: 100 - 120 VAC
- Color: Gray
- Finish: Smooth Gloss
- Thickness: 0.1 in / 2.5 mm
- Weight: 1.2 lb
DRAWINGS AND DOCUMENT DOWNLOADS
3D Step
Approval Agency Certificate
Installation Manual / Instruction Sheet
Spec Sheet / Engineering Specification
ADDITIONAL PRODUCT DETAILS
Perfect for offices, classrooms and other noise-sensitive areas. Fan Speed Control optimizes airflow in a cabinet or rack, balancing air volume requirements with noise level and power use.
BULLETIN NUMBER
DTHRM
INDUSTRY STANDARDS
UL 508 Listed; File No. E249700
cUL Listed per CSA C22.2 No. 14; File No. E249700
