Description
Belden 8241F J5C1000 Analog Video, RG59, 22 AWG Stranded BC, BC Braid, PVC Jacket
RG-59/U, 22 AWG stranded (7x30) .030" bare copper conductor, foam polyethylene insulation, bare copper braid shield (95% coverage), PVC jacket.
Ordering Details
- Manufacturer Part Number: 8241F J5C1000
- Color: Black, Vivid Matte
- Length: 1,000 ft
- Put-Up: Reel
- UPC/EAN: 612825355908
- Manufacturer Footnote: C
Supplied as one 1,000 ft Reel.
Construction Details
- RG Type: 59
- Size: 22; Stranding: 7x30; Nom. Diameter: 0.03 in; Material: BC - Bare Copper
- Material: PE - Polyethylene (Foam); Nom. Insulation Diameter: 0.146 in (3.71 mm)
- Outer Shield Type: Braid; Material: Bare Copper (BC); Coverage: 95%
- Material: PVC - Polyvinyl Chloride; Nom. Diameter: 0.241 in
Electrical Characteristics
- Frequency: 1 MHz; Nom. Attenuation: 0.3 dB/100ft; Max. Attenuation: 7.4 dB/100ft
- Frequency: 10 MHz; Nom. Attenuation: 0.9 dB/100ft
- Frequency: 50 MHz; Nom. Attenuation: 2.1 dB/100ft
- Frequency: 100 MHz; Nom. Attenuation: 3 dB/100ft
- Frequency: 200 MHz; Nom. Attenuation: 4.5 dB/100ft
- Frequency: 400 MHz; Nom. Attenuation: 6.6 dB/100ft
- Frequency: 700 MHz; Nom. Attenuation: 8.9 dB/100ft
- Frequency: 900 MHz; Nom. Attenuation: 10.1 dB/100ft
- Frequency: 1000 MHz; Nom. Attenuation: 10.9 dB/100ft
- Nom. Conductor DCR: 15 Ohm/1000ft (49 Ohm/km); Nom. Outer Shield DCR: 2.6 Ohm/1000ft (8.5 Ohm/km); Nom. Capacitance Cond-to-Shield: 17.3 pF/ft (56.8 pF/m); Nom. Characteristic Impedance: 75 Ohm; Nom. Velocity of Prop.: 78%
- Voltage Rating: 300 V RMS
Mechanical Characteristics
- Operating: -30°C To +60°C
- Max. Pull Tension: 65 lbs (29 kg)
- Bulk Cable Weight: 33 lbs/1000ft (49 kg/km)
Standards and Compliance
- Environmental Suitability: Indoor (Not Riser or Plenum), Indoor
- CPR Compliance: CPR Euroclass: Fca
- European Directive Compliance: EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
- APAC Compliance: China RoHS II (GB/T 26572-2011)
History
- Update and Revision: Revision Number: 0.341 Revision Date: 11-06-2026
- Footnote: C - CRATE REEL PUT-UP.
