Product Overview
Features
USB-C to SATA Adapter Connects 2 SATA Drives to Your Device’s USB-C or Thunderbolt 3 Port
This dual-drive USB 3.1 Type-C to SATA quick dock allows you to quickly and easily add extra storage space to your computer, tablet, laptop, notebook, MacBook, Ultrabook or Chromebook. The plug-and-play unit connects to your device’s USB Type-C or Thunderbolt 3 port using the included USB 3.1 Gen 2 cable. Just insert up to two 2.5- or 3.5-inch SATA drives into the top slots, and activate the on/off switch. LEDs indicate the unit is receiving power and the SATA drives are ready to use.
One-Touch Cloning Allows Easy Drive Duplication
You can duplicate the contents of one SATA drive onto a second drive without connecting to a host computer. Just insert the SATA master drive into the unit’s Master slot, and insert the SATA replica drive into the Replica slot. Press the Clone button. A progress bar illuminates to indicate cloning progress.
Complies with USB 3.1 Gen 2 Standards for Ultra-Fast File Transfers
This USB Type-C to SATA adapter supports USB 3.1 Gen 2 data transfer speeds up to 10 Gbps. It is backward compatible with previous USB 3.0 and USB 2.0 generations, so you can use it with older USB devices and cables. It also reads data up to 70 percent faster and writes up to 40 percent faster when connected to a UASP-enabled host controller.
Works with Most SATA Drives
The dock accepts 2.5-inch and 3.5-inch SATA I, II and III hard disc drives (HDDs) and solid state drives (SSDs) up to 10 TB (and higher-capacity drives when they become available, up to 16TB). It also works with all major operating systems, including Windows, Mac and Linux.
System Requirements
- Computer with USB-C or Thunderbolt 3 port (USB 3.1 Gen 2 port required to achieve maximum speeds)
- 2.5 in. or 3.5 in. SATA HDD or SSD
- Any major operating system that complies with USB standards
Package Includes
- U439-002-CG2 USB 3.1 Gen 2 USB-C to SATA Hard-Drive Quick Dock
- External power supply (Input: 100–240V, 50/60 Hz, 1.5A; Output: 12V 3A)
- USB 3.1 Gen 2 (10 Gbps) USB-C cable (M/M), 3 ft.
- Owner’s manual
Specifications
OVERVIEW
| UPC Code | 037332231185 |
| Technology | SATA/eSATA |
INPUT
| Voltage Compatibility (VAC) | 100; 110; 120; 127; 200; 208; 220; 230; 240 |
POWER
| AC Adapter | Input: 100-240V, 50/60Hz, 1.5A; Output: 12V, 3A |
| External Power Supply Input Specs (V / Hz / A) | 100-240V / 50/60Hz / 1.5A |
| External Power Supply Output Specs (V / A) | 12V / 3A |
| External Power Supply Cord Length (ft.) | 5.0 |
| External Power Supply Cord Length (m.) | 1.5 |
| DC Barrel Plug | OD: 5.5 x 2.1 x 10mm, Positive Pin, Negative Sleeve |
| External Power Supply Plug(s) | NEMA 1-15P North America |
USER INTERFACE, ALERTS & CONTROLS
| LED Indicators | Blue (Read, Write, Power); Red (Clone) |
PHYSICAL
| Material of Construction | PCB |
| Color | Black |
| Shipping Dimensions (hwd / in.) | 2.83 x 7.95 x 6.30 |
| Shipping Weight (lbs.) | 0.86 |
| Unit Dimensions (hwd / in.) | 4.4 x 6 x 2.4 |
| Unit Packaging Type | Box |
| Unit Weight (lbs.) | 1.00 |
ENVIRONMENTAL
| Operating Temperature Range | 50 to 122 F (10 to 50 C) |
| Storage Temperature Range | 32 to 149 F (0 to 65 C) |
| Relative Humidity | 10% to 80% RH, Non-Condensing |
CONNECTIONS
| Number of Ports | 2 |
| Side A - Connector 1 | USB C (FEMALE) |
| Side B - Connector 1 | (2) 7-PIN SATA (FEMALE) |
| Connector Plating | Nickel |
FEATURES & SPECIFICATIONS
| USB Specification | USB 3.1 Gen 2 (up to 10 Gbps) |
| Driver Required | No |
| UASP Support | Yes |
STANDARDS & COMPLIANCE
| Certifications | Tested to FCC, RoHS, REACH |
| External Power Supply Certifications | FCC; UL; cUL; RoHS |
WARRANTY
| Product Warranty Period (Worldwide) | 3-year limited warranty |
