Product Overview
DESCRIPTION
Power Supply, 960W, 100-240VAC 1PH, 24-28VDC, 40-34.3A
FEATURES
- AC 100-240V wide-range input
- Width only 110mm, weight only 1.9kg
- 94.6% full load and excellent partial load efficiencies
- 50% BonusPower, 1440W for up to 4s
- 110A high peak current for 10ms for easy fuse tripping
- Safe HiccupPLUS overload mode
- Active power factor correction (PFC)
- Negligibly low input inrush current
- Full power between -25°C and +60°C
- Current sharing feature for parallel use
- Internal data logging for troubleshooting included
- Remote control of output voltage
- DC-OK relay contact
- Shut-down input
- ATEX and IECEx approved
RESOURCES
Other Information
PULS orders require a $400 combined order minimum. This item is fulfilled by a 3rd Party and is subject to availability and possible order minimums. PULS orders are Non-Cancelable/Non-Returnable.
DESCRIPTION
Power Supply, 960W, 100-240VAC 1PH, 24-28VDC, 40-34.3A
FEATURES
- AC 100-240V wide-range input
- Width only 110mm, weight only 1.9kg
- 94.6% full load and excellent partial load efficiencies
- 50% BonusPower, 1440W for up to 4s
- 110A high peak current for 10ms for easy fuse tripping
- Safe HiccupPLUS overload mode
- Active power factor correction (PFC)
- Negligibly low input inrush current
- Full power between -25°C and +60°C
- Current sharing feature for parallel use
- Internal data logging for troubleshooting included
- Remote control of output voltage
- DC-OK relay contact
- Shut-down input
- ATEX and IECEx approved
RESOURCES
PULS orders require a $400 combined order minimum. This item is fulfilled by a 3rd Party and is subject to availability and possible order minimums. PULS orders are Non-Cancelable/Non-Returnable.
