Product Overview
DESCRIPTION
Redundancy Power Supply, 240W, 100-240VAC 1PH, 24VDC, 10A with Plug Connectors & Conformal Coating
FEATURES
- DC 110-300V wide-range input
- Width only 39mm
- Built-in decoupling MOSFET for 1+1 and n+1 redundancy
- Efficiency up to 94.7%
- 20% output power reserves
- Safe HiccupPLUS overload mode
- Easy fuse breaking – 3 times nominal current for 12ms
- Active Power Factor Correction (PFC)
- Minimal inrush current surge
- Full power between -25°C and +60°C
- Current sharing feature included
- DC-OK relay contact
- Plug connectors, hot swappable
RESOURCES
Other Information
PULS orders require a $400 combined order minimum. This item is fulfilled by a 3rd Party and is subject to availability and possible order minimums. PULS orders are Non-Cancelable/Non-Returnable.
