Description
StructuredGround™ Single Cable U-Bolt Grounding Clamp
StructuredGround™ GPL-34-3 Bronze Grounding Clamp, U-Bolt, single cable
Our single cable U-Bolt grounding clamp simplifies installation with its versatile design, accommodating various pipe, tube, rod, and conductor sizes for efficient grounding.
Specifications
- Sub Brand: StructuredGround™
- Material: Bronze/Silicon Bronze
- Copper Conductor Size: 4 AWG-250 kcmil
- Iron Pipe Size (In.): 2
- Iron Pipe Size (mm): 50.8
- Number of Wires: 1
- Overall Length (In.): 3.75
- Overall Length (mm): 95.3
- Overall Width (In.): 1.63
- Overall Width (mm): 41.4
- Overall Height (In.): 4.25
- Overall Height (mm): 107.9
- Bolt Diameter (In.): 3/8
- Bolt Diameter (mm): 9.5
- Hex Size (In.): 9/16
- Hex Size (mm): 14.3
- Application: Utility/Ground Grid
- Standards Met: cULus Listed 467, DB Rated
- Surface Treatment: Galvanic/electrolytic zinc plated
- Product Type: U-Bolt Grounding Clamp
- Part Features: Accommodates a wide range of pipe, tube, rod and conductor sizes, minimizing inventory requirements, saving cost.
Manufacturer Standard Package Quantity: 3
