Panduit GPL-33-3

$14,613.99
SKU:
GPL-33-3
Shipping:
Calculated at Checkout
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

StructuredGround™ Single Cable U-Bolt Grounding Clamp

StructuredGround™ GPL-33-3 Bronze Grounding Clamp, U-Bolt, single cable

Our single cable U-Bolt grounding clamp simplifies installation with its versatile design, accommodating various pipe, tube, rod, and conductor sizes for efficient grounding.

Specifications

  • Sub Brand: StructuredGround™
  • Material: Bronze/Silicon Bronze
  • Copper Conductor Size: 2/0 AWG
  • Iron Pipe Size (In.): 2
  • Iron Pipe Size (mm): 52
  • Number of Wires: 1
  • Overall Length (In.): 3.25
  • Overall Length (mm): 82.6
  • Overall Width (In.): 1.88
  • Overall Width (mm): 47.8
  • Overall Height (In.): 4
  • Overall Height (mm): 101.6
  • Bolt Diameter (In.): 3/8
  • Bolt Diameter (mm): 9.5
  • Hex Size (In.): 9/16
  • Hex Size (mm): 14.3
  • Application: Utility/Ground Grid
  • Standards Met: cULus Listed 467, DB Rated
  • Surface Treatment: Galvanic/electrolytic zinc plated
  • Product Type: U-Bolt Grounding Clamp
  • Part Features: Accommodates a wide range of pipe, tube, rod and conductor sizes, minimizing inventory requirements, saving cost.

Manufacturer Standard Package Quantity: 3
