Description
Pan-Term® Nylon-Insulated Female Disconnect
Pan-Term® DNF18-110-C Loose Piece Disconnect
Ensure reliable performance with our nylon-insulated female disconnect, ideal for wiring various electrical projects.
Specifications
- Disconnect Type: Female Disconnect
- Insulation Material: Nylon
- Insulation Type: Barrel Insulated
- Copper Conductor Size: 22-18 AWG
- Wire Size: 22-18 AWG
- Wire Strip Length (In.): 9/32
- Wire Strip Length (mm): 7.1
- Tab Size (In.): 0.110 x 0.032
- Tab Size (mm): 2.8 x 0.8
- Standards Met: UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153
- Maximum Voltage (V): 300
- Base Material: Brass
- Finish/Coating: Tin-Plated
- Color Code: Red
- Barrel Type: Funnel Entry
- Flammability Rating: UL 94 HB
- Insulation Diameter (In.): 0.1
- Insulation Diameter (mm): 2.5
- Maximum Operating Temperature (°C): 90
- Maximum Operating Temperature (°F): 194
- Sub Brand: Pan-Term®
- Maximum Metric Conductor Size (mm²): 1
- Minimum Metric Conductor Size (mm²): 0.5
- Maximum Wire Insulation Diameter (In.): 0.1
- Maximum Wire Insulation Diameter (mm): 2.5
- Overall Length (In.): 0.69
- Overall Length (mm): 17.5
- Overall Width (In.): 0.15
- Overall Width (mm): 3.8
- Overall Thickness (In.): 0.1
- Overall Thickness (mm): 0.2
- Tongue Angle: Straight
- Packaging Type: Bottle
- Product Type: Disconnect
- For Use With: CT-1525, CT-2300/ST (CD-525), CT-2500/L (CT-2525CH), UP14ZLW (CD-525)
- Maximum Voltage (kV): 0.3
- Part Features: • Disconnect can be inserted and removed from the male tab without the use of tools for lower installed cost • Metal insulation grip sleeve crimps to wire insulation, providing protection to the crimp joint during high vibration applications • Internal barrel serrations assure good wire contact and maximum tensile strength • Internal wire stop assures proper length of insertion into terminal barrel, providing a higher quality connection • UL Flammability UL 94V-2/HB, maximum insulation temperature 194°F (90°C) • UL and CSA rated up to 300 V per UL 310, where applicable
Manufacturer Standard Package Quantity: 100
