Description
Pan-Term® Nylon-Insulated Female Disconnect
Pan-Term® DNF18-206-C Loose Piece Disconnect
Ensure reliable performance with our nylon-insulated female disconnect, ideal for wiring various electrical projects.
Specifications
- Disconnect Type: Female Disconnect
- Insulation Material: Nylon
- Insulation Type: Barrel Insulated
- Copper Conductor Size: 22-18 AWG
- Wire Size: 22-18 AWG
- Wire Strip Length (In.): 9/32
- Wire Strip Length (mm): 7.1
- Tab Size (In.): 0.205/0.187 x 0.020
- Tab Size (mm): 5.2/4.8 x 0.5
- Standards Met: UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153
- Maximum Voltage (V): 300
- Base Material: Brass
- Finish/Coating: Tin-Plated
- Color Code: Red
- Barrel Type: Funnel Entry
- Flammability Rating: UL 94 HB
- Insulation Diameter (In.): 0.14
- Insulation Diameter (mm): 3.5
- Maximum Operating Temperature (°C): 90
- Maximum Operating Temperature (°F): 194
- Sub Brand: Pan-Term®
- Maximum Metric Conductor Size (mm²): 1
- Minimum Metric Conductor Size (mm²): 0.5
- Maximum Wire Insulation Diameter (In.): 0.14
- Maximum Wire Insulation Diameter (mm): 3.5
- Overall Length (In.): 0.76
- Overall Length (mm): 19.3
- Overall Width (In.): 0.25
- Overall Width (mm): 6.4
- Overall Thickness (In.): 0.16
- Overall Thickness (mm): 0.4
- Tongue Angle: Straight
- Packaging Type: Bottle
- Product Type: Disconnect
- For Use With: CT-1550, CT-1551, CT-2300/ST (CD-550), CT-2500/L (CT-2550CH), UP14ZLW (CD-550)
- Maximum Voltage (kV): 0.3
- Part Features: • Disconnect can be inserted and removed from the male tab without the use of tools for lower installed cost • Metal insulation grip sleeve crimps to wire insulation, providing protection to the crimp joint during high vibration applications • Internal barrel serrations assure good wire contact and maximum tensile strength • Internal wire stop assures proper length of insertion into terminal barrel, providing a higher quality connection • UL Flammability UL 94V-2/HB, maximum insulation temperature 194°F (90°C) • UL and CSA rated up to 300 V per UL 310, where applicable
- Manufacturer Status: Discontinued - Limited Stock
Manufacturer Standard Package Quantity: 100
