Product Overview
DESCRIPTION
Voltage band relay for 24 VDC, 15 Amp relay, DPDT, Adj Pick up and Drop out, Adj dropout delay 0.1-10 seconds, DIN
As long as the monitored voltage (Un) remains within the OVER (Umax) & UNDER (Umin) voltage settings, the internal relay stays energized. If the monitored voltage falls outside this range, the relay will drop-out. The Umax dial sets the upper limit per the Overvoltage range of the product. The Umin dial sets the lower limit at 30-95% of the upper setting. This product has an adjustable time delay on drop-out of 0.1-10 seconds (t) to prevent nuisance tripping.
FEATURES
- Provides voltage band (window) protection
- Wide range of user-adjustable Over Voltage and Under Voltage settings
- 15A SPDT output contacts
- Adjustable time delay on drop-out of 0.1 - 10 seconds
- LEDs indicate nominal voltage & output relay status
