DESCRIPTION
Timer, True Off Delay, 48V AC/DC, 10 amp DPDT, 50ms-30min
Upon application of input voltage, the relay is energized. When the input voltage is removed, the preset time begins. At the end of the preset time, the relay is de-energized. Voltage must be applied for a minimum of 0.1 second to assure proper operation. Any application of the input voltage during the preset time will keep the relay energized & reset the time delay. No external trigger switch is required.
FEATURES
- Each unit has 8 timing ranges built-in covering 0.1 seconds-30 minutes
- Selecting a range is easy using a rotary switch (no math is required or DIP switches to set)
- 10A output contacts can handle most pilot duty & fractional HP loads
