DESCRIPTION
Seal Leak Relay, Dual Channel, 4.7-100K Ohms, 240V AC Input,(2) 5 Amp SPNO Relay, Plug-in
Two wires from the relay are connected to a resistance-sensing probe in the pump seal cavity and the grounded motor housing or across two probes to monitor for seal leakage using a low-voltage DC signal. If the seal starts to leak, contaminating fluid enters the seal cavity. This lowers the resistance between the internal probe and the common connection. When the resistance drops below the user-adjustable sensitivity set-point of the relay, the output relay energizes and the LED turns Red ON. The relay output can be used to give an alarm indication of a leaking seal.
FEATURES
Monitors Submersible Pump Seals for Leakage Two Adjustable Sensitivity Ranges Full Status Indication on Top of Unit for Easy Troubleshooting Low-Profile Adjustment Knob 8 Pin Back-Mounted Socket Provided with Relay
