Product Overview
DESCRIPTION
Model ES-62T produces excellent intelligibility for speech and full-frequency response for music making it ideal for retail, commercial, industrial, institutional, and residential applications. This self-contained in-ceiling speaker system with 6-1/2 inch coaxial driver has a high-frequency PEI tweeter with acoustic lens to provide the kind of crisp, high-frequency response expected from high quality coaxial speakers. The ported enclosure is tuned for extended low-frequency response, while the speaker’s wide dispersion can actually reduce the number of speakers required to produce even coverage in distributed speaker systems.
FEATURES
- Driver: 6.5 in. coaxial driver with high-frequency PEI tweeter/acoustic lens
- Transformer: 32W (tap selector behind grille). Taps for 25V, 70V or 100V speaker systems, and 4 ohm (UL min.) transformer bypass position.
- Enclosure: Painted (grey) steel back-can with mounting dogs
- Grille: Press-fit grille with scrim, pull-tool
- Mounting Aids: Plastic paint shield to protect driver, C-ring and support rails
- Installs in drywall, wood, tile or almost any ceiling with thickness up to 2-1/8 inches.
RESOURCES
