Product Overview
Fan Shroud Kits Type 3R, fits 10-inch fan, Brushed, Stainless Steel 304
- Two fan shrouds per package
- Perforated ventilation screen
- Pressure-sensitive adhesive-backed gasket and mounting hardware
PRODUCT ATTRIBUTES
- Height: 12 in / 305 mm
- Width: 12 in / 305 mm
- Depth: 4.71 in / 120 mm
- Protection Rating: NEMA Type 3R
- Material: Stainless Steel 304
- Finish: Brushed #4
- Color: Unpainted
- Thickness: 16 ga / 1.59 mm
- Dimensions: 12.00 x 12.00 in / 305 x 305 mm
- Weight: 10.5 lb
DRAWINGS AND DOCUMENT DOWNLOADS
2D DXF
3D Step
Approval Agency Certificate
Installation Manual / Instruction Sheet
Spec Sheet / Engineering Specification
ADDITIONAL PRODUCT DETAILS
Fan Shroud Kit, Type 3R, protects enclosure openings from rain, sleet and snow. It comes with a gasket, ventilation screen, and is available in both painted mild steel and stainless steel.
BULLETIN NUMBER
D85
Other Information
Hoffman has a $50 fee on all air orders. This fee will be incorporated into the shipping price. Hoffman orders of $7500 or more ship for free.
