Product Overview
Syspend 281-Max 48mm Round Tube Coupling Adapter, .6x3.15x3.15, Black, Aluminum
- Gasket and mounting hardware are included
PRODUCT ATTRIBUTES
- Height: 0.59 in / 15 mm
- Width: 3.15 in / 80 mm
- Depth: 3.15 in / 80 mm
- Material: Aluminum
- Color: Jet Black
- Color Code: RAL 9005
- Finish: Powder Coated
- Weight: 0.5 lb
DRAWINGS AND DOCUMENT DOWNLOADS
2D DXF
3D Step
Approval Agency Certificate
Installation Manual / Instruction Sheet
Spec Sheet / Engineering Specification
ADDITIONAL PRODUCT DETAILS
Syspend 281-Max 48-mm Round Tube Flange Coupling attaches the Vertical Motion Pedestal Tube or any 48-mm round tube to the enclosure. Enclosure can be rotated 300 degrees and locked in position. Includes safety stop and maintenance-free bearing.
Syspend 281-Max Adapter is required to attach the Flange Coupling to a standard HOFFMAN HMI enclosure that uses a 60 x 60-mm hole pattern (i.e. Syspend Aluminum HMI and Concept HMI). Adapter is not required as the Coupling attaches to enclosure using a 48 x 48-mm hole pattern directly.
