Product Overview
Hazloc Cable Glands for Non Armored Cable, Non-Metallic (Ex e/tb)
- Suitable for non-armored cables in increased safety (ex e) and dust (ex tb) applications
- Provide high level of protection and reliability in extreme environments with impact resistance of up to 7 Joules
- All metric thread cable glands are packaged as kits
- Each kit includes a chloroprene washer, a locknut and an earthtag
- Includes chloroprene seal
- Available in Metric (M) and NPT (N) thread type
- Operating temperature from -40 C to 70 C with chloroprene seal
PRODUCT ATTRIBUTES
- Size: NPT1/2"
- Clamping Range Diameter: 7.0-12.0 mm / 0.28-0.47 in
- Min H: 23 mm
- Seal: Chloroprene
- Color: Dark Gray
- Finish: Smooth Matte
- Material: Polyamide 6
- Weight: 0.1 lb
DRAWINGS AND DOCUMENT DOWNLOADS
2D DXF
3D Step
Approval Agency Certificate
Data Sheet
Installation Manual / Instruction Sheet
ADDITIONAL PRODUCT DETAILS
Hazloc cable glands provide strain relief, sealing and secure entry of cables into enclosures or electrical equipment in hazardous areas. Suitable for Zone 1, 2, 21 or 22 with ATEX and IEC certifications, these cable glands are reliable to protect critical processes and people where explosive gas and dust may be present. Available in various thread types and sizes, our hazloc cable glands are designed to be used in many applications and under extreme environments.
BULLETIN NUMBER
