Description
Panel 19-inch Bottom-Hinged 4U, 203x508x305mm, Black, Steel
- Hinged panel pivots to 90 degrees with positive stop, providing a stable platform for punch-down interconnects
- Thumbscrews secure the panel in the upright position
- Integral Velcro® cable tiedown slots facilitate cable routing
- Cover protects equipment and cables
- Shipped fully assembled
PRODUCT ATTRIBUTES
- Height: 8 in / 203 mm
- Width: 20 in / 508 mm
- Depth: 12 in / 305 mm
- Material: Mild Steel
- Rack Units: 4
- Load Rating: 25 lb / 11.3 kg
- Body Thickness: 16 ga / 1.5 mm
- Color: Jet Black
- Color Code: RAL 9005
- Door Thickness: 12 ga / 2.7 mm
- Finish: Powder Coated
- Weight: 19.76 lb
DRAWINGS AND DOCUMENT DOWNLOADS
2D DXF
3D Step
Approval Agency Certificate
Data Sheet
Installation Manual / Instruction Sheet
ADDITIONAL PRODUCT DETAILS
Hinged panel pivots to 90 degrees with positive stop, providing a stable platform for punch-down interconnects. Thumbscrews secure the panel in the upright position. Integral Velcro® cable tiedown slots facilitate cable routing. Cover protects equipment and cables. Shipped fully assembled. Velcro® is a trademark of Velcro Industries B.V.
BULLETIN NUMBER
DOFRW
