Product Overview
Dual Thermostat, 2.64x1.97x1.81, Lt Gray, Plastic
- Two thermostats; one normally closed (NC), red, and one normally open (NO), blue, in one casing
- Wide adjustable temperature range (32 -140 F)
- Thermostatic bimetallic sensor element
- Connection is a 4-pole terminal for AWG 14 max (2.5 mm sq)
- Mounting clip for 35-mm DIN rail
PRODUCT ATTRIBUTES
- Height: 2.64 in / 67 mm / 67 mm
- Width: 1.97 in / 50 mm / 50 mm
- Depth: 1.81 in / 46 mm / 46 mm
- Material: Plastic
- Color: Light Gray
- Color Code: RAL 7035
- Finish: Smooth Matte
- Weight: 0.22 lb
DRAWINGS AND DOCUMENT DOWNLOADS
2D DXF
3D Step
Approval Agency Certificate
Data Sheet
Installation Manual / Instruction Sheet
ADDITIONAL PRODUCT DETAILS
Two thermostats in one, the Dual Thermostat independently controls equipment heating and cooling systems.
BULLETIN NUMBER
D85
INDUSTRY STANDARDS
cURus; File No. E164102
CSA File No. 215952
CE
Other Information
Hoffman has a $50 fee on all air orders. This fee will be incorporated into the shipping price. Hoffman orders of $7500 or more ship for free.
