Belden 8402 001500 Microphone Cable, 2 Conductor 20 AWG, TC - Brown, 500 ft Reel

$2,783.99
SKU:
8402 001500
Shipping:
Calculated at Checkout
Color:
Brown
Length:
500 ft
Put-Up:
Reel
Manufacturer Status:
Active
Product Family:
8402
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Belden 8402 001500 Microphone Cable, 2 Conductor 20 AWG, TC

20 AWG stranded (26x34) high-conductivity TC conductors, EPDM rubber insulation, rayon braid, TC braid shield (85% coverage), cotton wrap, CSPE - Chlorosulphonated Polyethylene jacket.

Ordering Details

  • Manufacturer Part Number: 8402 001500
  • Color: Brown
  • Length: 500 ft
  • Put-Up: Reel
  • UPC/EAN: 612825206101
  • Manufacturer Footnote: C

Supplied as one 500 ft Reel.

Image is for illustration only. Actual cable color and packaging may vary. Refer to the listed color, length, and put-up for this part number.

Product Overview

  • Suitable Applications: Ruggedized, deployable microphone for studio or live performance; Balanced analog audio

Construction Details

  • No. of Elements: 2; Size: 20; Stranding: 26x34; Material: TC - Tinned Copper (High Conductivity)
  • Material: EPDM - Ethylene Propylene Diene Monomer; Nom. Insulation Diameter: 0.083 in (2.1 mm); Color Code: White, Black
  • Shield Type: Braid; Material: Rayon®; Coverage: 85%
  • Shield Type: Braid; Material: Tinned Copper (TC); Coverage: 85%
  • Separator: Cotton Serve; Material: CSPE - Chlorosulphonated Polyethylene; Nom. Thickness: 0.035 in (0.89 mm); Nom. Diameter: 0.263 in

Electrical Characteristics

  • Nom. Conductor DCR: 10.2 Ohm/1000ft (33.5 Ohm/km); Nom. Capacitance Cond-to-Cond: 30 pF/ft (98 pF/m); Nom. Capacitance Cond-to-Other (Conds + Shield): 55 pF/ft (180 pF/m); Nom. Characteristic Impedence: 52 Ohm; Nom. Inductance: 0.18 µH/ft (0.59 µH/m); Max. Current: 4 Amps per Conductor at 25ºC
  • Nom Outer Shield DCR: 3 Ohm/1000ft (9.8 Ohm/km)
  • Voltage Rating: 600 V RMS

Mechanical Characteristics

  • Operating: -20°C To +60°C
  • Max. Pull Tension: 98 lbs (44 kg)
  • Bulk Cable Weight: 50 lbs/1000ft (74 kg/km)

Standards and Compliance

  • Environmental Suitability: Indoor (Not Riser or Plenum), Indoor
  • Flammability / Reaction to Fire: VW-1
  • European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
  • APAC Compliance: China RoHS II (GB/T 26572-2011)

History

  • Update and Revision: Revision Number: 0.380 Revision Date: 11-06-2026
  • Footnote: C - CRATE REEL PUT-UP.
