Description
Belden 5100FE 008500 Security & Sound, 2 Conductor 14 AWG, BC, Shielded, CL3R, FPLR
Security & Commercial Audio Cable, Riser-CL3R-FPLR, 2-14 AWG stranded bare copper conductors with polypropylene insulation, Beldfoil® shield and PVC jacket with ripcord
Ordering Details
- Manufacturer Part Number: 5100FE 008500
- Color: Gray
- Length: 500 ft
- Put-Up: Reel
- UPC/EAN: 612825156222
Supplied as one 500 ft Reel.
Product Overview
- Suitable Applications: Intercom/PA Systems, Sound/Audio Systems, Fire Alarm Systems
Construction Details
- Element: Conductor(s); No. of Elements: 2; Size: 14 AWG; Stranding: 19x26; Material: BC - Bare Copper
- Element: Conductor(s); Material: PP - Polypropylene; Nom. Thickness: 0.011 in (0.28 mm); Nom. Insulation Diameter: 0.092 in (2.3 mm); Color Code: Black, White
- Shield Type: Tape; Material: Bi-Laminate (Alum+Poly); Coverage: 100%; Drainwire Type: 22 AWG (7x30) TC
- Material: PVC - Polyvinyl Chloride; Nom. Thickness: 0.017 in (0.43 mm); Nom. Diameter: 0.222 in (5.64 mm); Ripcord: Yes
- Overall Cable Diameter (Nominal): 0.222 in (5.64 mm)
Electrical Characteristics
- Element: Conductor(s); Nom. Conductor DCR: 2.54 Ohm/1000ft; Nom. Capacitance Cond-to-Cond: 54 pF/ft (180 pF/m); Nom. Capacitance Cond-to-Other (Conds + Shield): 97.25 pF/ft (319.1 pF/m); Nom. Inductance: 0.15 µH/ft (0.49 µH/m); Max. Current: 25 Amps per conductor @ 30°C
- Nom Outer Shield DCR: 10 Ohm/1000ft (33 Ohm/km)
- UL Voltage Rating: 300 V (CL3R, FPLR)
Mechanical Characteristics
- UL Temperature: 75°C; Operating: -20°C to +75°C
- Stationary Min.: 2.2 in (56 mm); Installation Min.: 2.2 in (56 mm)
- Max. Pull Tension: 104.1 lbs (47.22 kg)
- Bulk Cable Weight: 37 lbs/1000ft
Standards and Compliance
- Environmental Suitability: Indoor - Riser, Indoor
- Flammability / Reaction to Fire: UL 1666 Riser, IEEE 1202 FT4, IEC 60332-1-2
- CPR Compliance: CPR Euroclass: Eca
- NEC / UL Compliance: Article 725, Article 760, CL3R, FPLR
- European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
- UK Regulation Compliance: UKCA Mark
- APAC Compliance: China RoHS II (GB/T 26572-2011)
- Plenum Number: 6100FH
History
- Update and Revision: Revision Number: 0.531 Revision Date: 02-20-2026
- Footnote: C - CRATE REEL PUT-UP.
