DESCRIPTION
The Atlas Power Vertical Power Strips offer complete power management, multiple outlet spacing and outlet orientations, and RFI filtering along with spike/surge protection to make them the most compact, effective power management protection systems on the market today. The AP-2410-15S is 24" rack mountable and features 15A, 1875W power capability.
Note: If this product will be mounted in a Texas Tough cabinet, TT-CLIP mounting accessories are required.
FEATURES
- 10 Available 15A Outlets
- Slimline Designs, 1.62"W x 1.25"D
- Two AC Outlet Orientations: "In Line" and "90 Degree to Chassis"
- Lighted Main Power Switch
- Circuit Breaker Protection
- Three-Way Surge Suppression MOV Protection: H-N, H-G, N-G
- RFI Filtering
- AC Protect Indicator
- UL, cUL Listed
- Also Available in 72", 30 Outlet (AP-7230-15S) and 48", 20 Outlet (AP-4820-15S) Models
SPECIFICATIONS
| Outlets | NEMA 5-20R, Qty. 10 |
| Power Cord | 9' (2.74m), 12-gauge, AC Plug NEMA 5-20P |
| Load Rating | 1875W |
| MAX Current Protection | 15A AC Mains Breaker |
| Voltage Protection Rating | L-N: 500V, L-G: 500V, N-G: 500V / 3kA, 8/20µs |
| Energy Rating | 450 Joules, 8/20µs |
| Power Consumption | .5W |
| Height | 1.25" (31.75mm) |
| Length | 24" (609mm) |
| Width | 1.62" (41.10mm) |
| Weight | 2.1 lbs (.99kg) |
