Description
Network Managed 802.3bt 4PPoE Midspan, 8-port, 10/100/1000, 90W max per port (480W total power), Battery Charging, 115/230VAC
Altronix NetWay8BT is an 8-port networked Managed Midspan in a 1U rack enclosure. It provides PoE/PoE+/Hi PoE up to 90W (802.3bt compliant) power per port, 480W total max. and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup and embedded LINQ™ Technology to monitor, control, and report power and diagnostics from anywhere over the network.
Input
115VAC, 60Hz, 5.5A or 230VAC, 50/60Hz, 3A (auto-ranging)
Power
Unit supplies PoE output voltage (55V) and up to 90W max. full power per port.
Total power: 480W.
IEEE 802.3af, IEEE 802.3at and IEEE802.3bt compliant.
Short circuit protection.
Ethernet
Eight (8) ports for cameras/edge devices over ethernet.
Wire type: 4-pair CAT5e and higher.
Speed: 10/100/1000 Mbps.
Functions
Auto detection and protection of legacy non-PoE cameras/edge devices.
Indicators (LED)
Yellow and Green LED (by RJ45 jack):
IP Link status, 10/100/1000 Base-T/active.
Green LED Port status.
Battery Backup
Built-in battery charger (optional rack mount battery enclosure - RE2).
Automatic switchover to stand-by battery when AC fails.
LINQ Technology
SSL (Secure Socket Layer) security encryption.
User level security.
Built-in IP management allows for remote camera reset and monitoring.
Provides local and/or remote access to critical information via LAN/WAN
Email and Windows Dashboard Alert notifications report real-time diagnostics.
Event log tracks history.
Temperature
Operating: - 20ºC to 50ºC ( - 4ºF to 122ºF).
Storage: - 20º to 70ºC ( - 4ºF to 158ºF).
Relative Humidity 85% +/- 5%.
BTU/Hr. (approx.): 246 BTU/Hr.
Operating Altitude
Up to 2,000m.
