Description
FEATURES
- Amplifies Weak Video Signals caused by Splitting the Signal for Multiple Television Installations.
- Handles all Cable and Off-Air Signals
- Return Path for Cable Modem
- Bidirectional
- 11 dB Gain- 1 GHz
- Input: (1) 75 Ohm
- Output: (2) 75 Ohm
- Gain:
- Forward Path: 11 dB +/- 2
- Return Path: 7 dB +/- 2
- Frequency Range:
- Forward Path: 54-1000 MHZ
- Return Path: 5-40 MHz
- Noise Figure: < 4 dB
- Input/Output Return Loss: > 12 dB
- Insertion Loss: _ 5 dB
- Max Output Level @ _ 60 dB IMD: > 98
- DC Pass: Input/Output
- LED Indicator Light
- Metal Housing: Good RFI Shielding
- Power Supply: 12V DC- 50 Hz
