Description
FEATURES
- Improves Video Signals Where Signal is Weakened Because of Multiple Hookups Being Used Such as Several Televisions and VCRs
- Switchable Built-In FM Trap
- Easy Installation
- Low Noise Figure
- On/Off Light
- Integrated Circuit
- For Indoor Use
- Specifications:
- Band Width: 47-400 MHz / 470-900 MHz
- Gain: 25 dB VHF – 23 dB UHF
- Noise Figure: Low 5.4 dB- High 6.2 dB
- FM Trap Attenuation: 20 dB- 95-108 MHz
- Input: 75 Ohm Input
- Output: 75 Ohm Output
- Power Source: 117 VAC- 60 Hz
