Product Overview
Key Features
- Starview illumination technology provides crisp color image up to 0.005Lux (F1.6)
- Exceptional Video Quality with 5MP, 2592 x 1944 Resolution
- Super-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage Requirements
- Powerful, Smart IR LED Lights for 0Lux Night Time Operation up to 98 Feet
- 2.8mm fixed lens
- TRUE Day/Night and WDR functionality for all Lighting Conditions
- Two-way Audio, Corridor View, Backlight Compensation and 3D DNR (Digital Noise Reduction)
- Triple Video Streams, ONVIF Profile S Compliant
- Powerful Video Analytics such as Behavior, Exception, Identification and Statistical
- PoE &aMP"; 12VDC Power Options
- Built-in Micro-SD Card Slot enables local storage up to 256GB
- IP67 Weather Resistant and IK10 Vandal Resistant Rated Vandal Housing
- Optional Wall and Pendant Mounts Available
- Supported by uniview tec Guard Station Software and Guard Viewer Mobile App’s for iPhone and Android Devices
| Camera | |
|---|---|
| Sensor | 1/2.7", progressive scan , 5 megapixel, CMOS |
| Lens | 2.8mm@ F1.6 |
| Angle of View (H x V ) | 105.3° x 69.5° |
| Shutter | Auto/Manual, 1~1/100000 s |
| Minimum Illumination | Color: 0.005 Lux (F1.6, AGC ON); 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| IR LED Range | Up to 30m (98 ft) IR range |
| WDR | 120dB |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Maximum Frame Rate / Stream | Main Stream: 5MP (2592 x 1944) @20 fps; 5MP (2592 x 1944) @25fps (WDR OFF); 4MP (2560 x 1440) @30 fps; 3MP (2048x 1536) @30 fps; 2MP (1920 x 1080) @30 fps Sub: 2MP (1920 x 1080) @ 30fps Third Stream: D1 (720×576) @ 30fps |
| HLC, BLC, 9:16 Corridor, Defog | Supported |
| OSD, Privacy Mask, Motion Detection &aMP"; ROI | Up to 8 areas |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP |
| Compatible Integration | ONVIF (Profile S, Profile G), API |
| Network | RJ45, 10M/100M Base-TX Ethernet |
| Video Analytics | Behavior, Exception, Identification, Statistical |
| Local &aMP"; Network Storage | Micro-SD, up to 256GB; ANR |
| General | |
| Power | 12VDC +/- 25%, PoE (IEEE802.3 af); Max 5.5W |
| Dimensions (Ø x H) | Φ108.5 x 81 mm (Ø4.28” x 3.2”); 0.45kg (0.99lb) |
| Audio I/O &aMP"; Compression | 2 / 1 (Stereo); G.711 |
| Alarm I/O | 1 / 1 |
| Operating Temperature &aMP"; Humidity | -35°C ~ +60°C (-31°F ~ 140°F); Humidity: 10%~ 95% RH (non-condensing |
| Conformity Certifications | IP67, IK10; CE, FCC |
Other Information
Univew Technology orders of $500 or more ship free.
Key Features
- Starview illumination technology provides crisp color image up to 0.005Lux (F1.6)
- Exceptional Video Quality with 5MP, 2592 x 1944 Resolution
- Super-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage Requirements
- Powerful, Smart IR LED Lights for 0Lux Night Time Operation up to 98 Feet
- 2.8mm fixed lens
- TRUE Day/Night and WDR functionality for all Lighting Conditions
- Two-way Audio, Corridor View, Backlight Compensation and 3D DNR (Digital Noise Reduction)
- Triple Video Streams, ONVIF Profile S Compliant
- Powerful Video Analytics such as Behavior, Exception, Identification and Statistical
- PoE &aMP"; 12VDC Power Options
- Built-in Micro-SD Card Slot enables local storage up to 256GB
- IP67 Weather Resistant and IK10 Vandal Resistant Rated Vandal Housing
- Optional Wall and Pendant Mounts Available
- Supported by uniview tec Guard Station Software and Guard Viewer Mobile App’s for iPhone and Android Devices
| Camera | |
|---|---|
| Sensor | 1/2.7", progressive scan , 5 megapixel, CMOS |
| Lens | 2.8mm@ F1.6 |
| Angle of View (H x V ) | 105.3° x 69.5° |
| Shutter | Auto/Manual, 1~1/100000 s |
| Minimum Illumination | Color: 0.005 Lux (F1.6, AGC ON); 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| IR LED Range | Up to 30m (98 ft) IR range |
| WDR | 120dB |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Maximum Frame Rate / Stream | Main Stream: 5MP (2592 x 1944) @20 fps; 5MP (2592 x 1944) @25fps (WDR OFF); 4MP (2560 x 1440) @30 fps; 3MP (2048x 1536) @30 fps; 2MP (1920 x 1080) @30 fps Sub: 2MP (1920 x 1080) @ 30fps Third Stream: D1 (720×576) @ 30fps |
| HLC, BLC, 9:16 Corridor, Defog | Supported |
| OSD, Privacy Mask, Motion Detection &aMP"; ROI | Up to 8 areas |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP |
| Compatible Integration | ONVIF (Profile S, Profile G), API |
| Network | RJ45, 10M/100M Base-TX Ethernet |
| Video Analytics | Behavior, Exception, Identification, Statistical |
| Local &aMP"; Network Storage | Micro-SD, up to 256GB; ANR |
| General | |
| Power | 12VDC +/- 25%, PoE (IEEE802.3 af); Max 5.5W |
| Dimensions (Ø x H) | Φ108.5 x 81 mm (Ø4.28” x 3.2”); 0.45kg (0.99lb) |
| Audio I/O &aMP"; Compression | 2 / 1 (Stereo); G.711 |
| Alarm I/O | 1 / 1 |
| Operating Temperature &aMP"; Humidity | -35°C ~ +60°C (-31°F ~ 140°F); Humidity: 10%~ 95% RH (non-condensing |
| Conformity Certifications | IP67, IK10; CE, FCC |
