Product Overview
Features
USB-C to DVI Adapter Connects to Your Laptop's USB-C or Thunderbolt 3 Port
This USB Type-C to DVI adapter connects a DVI monitor or projector to the USB-C or Thunderbolt 3 port on your computer, tablet, laptop, notebook, MacBook, Chromebook, Ultrabook or smartphone. It's an ideal connector for multitasking, presenting video at trade shows and conferences, editing documents, playing online games and watching movies on a larger screen. It saves you money by allowing you to use your existing DVI display instead of buying a new monitor.
Supports USB-C DisplayPort Alternate Mode for Transmitting Video Signals
By connecting the USB-C cable to a source device that supports USB DisplayPort Alt Mode, you can output 1080p video to a compatible monitor or projector without installing special software drivers.
Transmits Crystal-Clear 1080p Video to a DVI Display
Connect the dual-link DVI-D male connector to a compatible display to transmit high-definition video resolutions up to 1920 x 1200 (1080p) at 60 Hz. and 24-bit Deep Color (8 bits per channel).
Reversible USB-C Connector Attaches in Either Direction
Unlike traditional USB cables that connect in only one direction, the reversible USB-C male connector plugs into a USB-C or Thunderbolt 3 port in either direction for a fumble-free connection every time.
Ready to Use Right from the Package, So You Can Plug and Play Immediately
The plug-and-play USB Type-C to DVI cable is specifically designed for use with the MacBook, Google Chromebook Pixel and other laptops, tablets and devices equipped with a USB-C or Thunderbolt 3 port. It requires no software, drivers or external power. The 10-ft. (3.05 m) (3-meter) length allows you great flexibility in placing the source and display devices where they're most convenient.
Typical Applications
- Connect your laptop to a DVI monitor in a lecture hall or conference room for a video presentation
- Add a secondary monitor to the MacBook, Chromebook or laptop in your office or home workspace
- Stream online video or games from your computer on a larger DVI display
Package Includes
- U444-010-DE USB-C to DVI Adapter Cable (M/M), White, 10-ft. (3.05 m)
System Requirements
- Source device with USB-C or Thunderbolt 3 port that supports USB DisplayPort Alternate Mode
- Display device with DVI input
Specifications
OVERVIEW
| UPC Code | 037332238757 |
| Product Type | Passive Cable |
| Technology | DVI |
VIDEO
| Max Supported Video Resolution | 1080p |
| Max Supported Color Depth | 24-bit True Color |
INPUT
| Bus Powered | Yes |
POWER
| USB Power Delivery (PD) Charging Support | No |
PHYSICAL
| Color | Black |
| Material of Construction | PVC |
| Cable Jacket Rating | VW-1 |
| Cable Length (ft.) | 10 |
| Unit Dimensions (hwd / in.) | 0.65 x 1.64 x 1.99 |
| Unit Packaging Type | Polybag |
ENVIRONMENTAL
| Operating Temperature Range | 32 ~ 113F (0 ~ 45C) |
| Storage Temperature Range | 14 ~ 158F (-10 ~ 70C) |
| Operating Humidity Range | 10% ~ 85% RH |
| Storage Humidity Range | 5% ~ 90% RH |
CONNECTIONS
| Side A - Connector 1 | DVI-D DUAL LINK (MALE) |
| Side B - Connector 1 | USB C (MALE) |
| Connector Plating | Nickel |
FEATURES & SPECIFICATIONS
| HDCP Specification | 1.3 |
| USB Specification | USB 3.0 (up to 5 Gbps); USB 3.1 Gen 1 (up to 5 Gbps) |
| Driver Required | No |
| UASP Support | No |
| Auto MDIX Support | No |
| Full Duplex Support | No |
| Suspend Mode Support | No |
| Remote Wakeup Support | No |
STANDARDS & COMPLIANCE
| Certifications | Tested to CE, FCC, RoHS, REACH |
WARRANTY
| Product Warranty Period (Worldwide) | 1-year limited warranty |
