Product Overview

Features

Connects 2 DB9 Devices to a USB-A Device

Recommended for connecting a modem, digital camera, PDA or ISDN terminal to your computer, laptop or tablet
Supports data transfer speeds up to 225 Kbps—twice as fast as a built-in serial port
No external power source required
Portable 6 ft. design fits perfectly into laptop bag
COM retention for automatic reassigning of COM values to ports in case of disconnection or reboot
Integrated FTDI FT232RL chipset

First-Rate Construction for Superior Signal Transfer

Premium foil and braid shielding for EMI/RFI noise protection
Molded nickel-plated connectors with gold-plated contacts for optimal signal quality
Integral strain relief for long life
Flexible PVC jacket easy to install in tight spaces

Broad Compatibility

Compatible with Windows, Mac and Linux operating systems

System Requirements

Computer or other device with available USB port and Windows XP or later, Mac OS X 10.3 and later, or Linux operating system

Package Includes

U209-006-2 2-Port USB to DB9 Serial FTDI Adapter Cable (M/M), 6 ft.
Driver CD
Owner’s manual

Specifications

OVERVIEW

UPC Code

037332198303

INPUT

Bus Powered

Yes

POWER

Power Consumption (Watts)

0.50

PHYSICAL

Material of Construction	PVC
Color	Black
Cable Jacket Color	Black
Cable Jacket Rating	VW-1
Cable Length (ft.)	6
Shipping Dimensions (hwd / in.)	2.00 x 4.90 x 5.00
Shipping Weight (lbs.)	0.40
Unit Packaging Type	Box
Unit Weight (lbs.)	0.13

ENVIRONMENTAL

Operating Temperature Range	32 to 104 F (0 to 40 C)
Storage Temperature Range	14 to 131 F ( -10 to 55 C)
Relative Humidity	5% to 90% RH, Non-Condensing
BTUs	1.7 BTU/Hr

CONNECTIONS

Number of Ports	2
Side A - Connector 1	USB A (MALE)
Side B - Connector 1	(2) DB9 (MALE)
Connector Plating	Nickel

FEATURES & SPECIFICATIONS

USB Specification	USB 2.0 (up to 480 Mbps)
Driver Required	Yes

STANDARDS & COMPLIANCE

Certifications

Tested to CE, FCC, RoHS, REACH, WEEE

WARRANTY

Product Warranty Period (Worldwide)

3-year limited warranty
