Tripp Lite's Power It! TLM615NCRA power strip offers reliable, convenient and cost-effective power distribution for appliances, power tools, lighting and other electrical equipment. Includes 6 right-angle NEMA 5-15R outlets, 15-ft. (4.57 m) AC power cord and keyhole mounting slots. Multi-outlet strip reduces cable clutter and enables the connection of multiple electrical devices to a single AC wall socket. Features rugged metal case to stand up to the most demanding environments, illuminated power switch with transparent cover to prevent accidental shutoff and 15A integrated circuit breaker to prevent dangerous overloads.
INPUT/OUTPUT: Input: NEMA 5-15P/Output: 6 NEMA 5-15R
ELECTRICAL: 120V AC, 50/60Hz, 15A
FORMAT: Corded power distribution strip with right-angle outlets
Features
Multi-outlet power strip offers reliable, convenient and cost-effective power distribution for appliances, power tools, lighting and other electrical equipment
Includes 6 right-angle NEMA 5-15R outlets
Illuminated on/off switch provides one-touch power control for connected equipment
Transparent switch cover snaps tight to prevent accidental shutoff
Convenient keyhole slots provide secure mounting options for a wide variety of surfaces and applications
15A power handling capacity with integrated circuit breaker
120V AC, 50/60Hz electrical compatibility
15-ft. (4.57 m) AC power cord
Rugged metal case provides extra safety and durability
UL certification
Package Includes
TLM615NCRA power strip
Warranty information
Instruction manual
Specifications
OVERVIEW
UPC Code
037332135681
INPUT
Nominal Input Voltage(s) Supported
120V AC
Recommended Electrical Service
15A 120V
Input Cord Gauge Type
14 gauge; SJT
Voltage Compatibility (VAC)
120
Input Plug Type
NEMA 5-15P
Input Cord Length (ft.)
15
OUTPUT
Frequency Compatibility
50 / 60 Hz
Output (Watts)
1800
Output Receptacles
(6) 5-15R
Circuit Breaker (amps)
15
Overload Protection
15A circuit breaker
Transformer Accommodation
(3) Yes
Outlet Orientation
Single row of 6 (right-angle)
Right-Angle Outlets
Yes
USER INTERFACE, ALERTS & CONTROLS
Switches
Illuminated on/off switch controls power to all outlets
Locking Switch Cover
Transparent switch cover snaps tight to prevent accidental shutoff
PHYSICAL
Material of Construction
Metal
Color
Light Gray
Power Cord Color
Light Gray
Housing Color
Light Gray
Mounting Holes or Slots
Yes
Slot or Hole Mount Measurement (Center to Center)
Distance between mounting tabs = 203.20mm; Distance between end tabs = 330.17mm
Outlets Measurement (Center to Center)
41.3mm
Receptacle Color
Light gray
Shipping Dimensions (hwd / in.)
15.50 x 2.40 x 6.50
Shipping Weight (lbs.)
3.00
Unit Dimensions (hwd / in.)
13.75 x 2.5 x 2
Unit Weight (lbs.)
2.8
Mounting Details
Includes flanges
STANDARDS & COMPLIANCE
Canada
cUL
Additional International Approvals
Complies with RoHS (Restriction of Hazardous Substances Directive)
