Description
Features
3U Blanking Panel Helps Improve Rack Cooling Efficiency and Optimize Airflow
This cold-rolled steel SmartRack® blanking panel with a black powder-coated finish fills 3U of unused space in your EIA-standard 19-inch rack. Not only does this give your rack a sleek, clean look, but it also protects your valuable equipment by improving airflow and cooling efficiency. This reduces operating costs, improves performance and provides longer lifespans for your equipment.
High-Performance Fans Keep Equipment Cool in Crowded Server Rack Enclosures
Two built-in four-inch 12VDC fans mount into the rack and pull cool air from the outside. The included 12V DC power supply features a 6-ft. (1.83 m) cord and NEMA 1-15P plug that connects to an AC wall outlet, PDU or UPS system.
Helps You Precisely Measure Your Rack Temperature, Even High Up
The SRFAN3UTEMP can help you notice hot spots at any section of your rack with the included temperature sensor. The 6-ft. (1.83 m) sensor reaches every crack and crevice within your rack and finds hot spots that need to be cooled with the fans. The sensor accurately measures the rack temperature within 2°F and 1°C and a range of -58°-302°F and -50°-150°C.
LCD Indicator Lets You Keep a Close Watch on Environmental Changes
A front-panel LCD lets you monitor the rack temperature in either Fahrenheit or Celsius. One front rocker switch flips between °F and °C. The other turns the SRFAN3UTEMP on and off.
Package Includes
- SRFAN3UTEMP 3U Blanking Panel
- Temperature sensor
- 12V DC power supply with 6-ft. (1.83 m) cord and NEMA 1-15P plug
- Rack-mounting hardware
- Owner's manual
Specifications
OVERVIEW
| UPC Code | 037332240620 |
| Accessory Type | Temperature Sensor |
| Accessory Class | Cooling Accessories |
INPUT
| Nominal Input Voltage(s) Supported | 120V AC |
| Nominal Input Voltage Description | 120V 60Hz |
| Input Plug Features | Nema 1-15p |
| Input Cord Length (ft.) | 6 |
COOLING
| Cooling Type | Active |
| Airflow | 202.6 CFM |
PHYSICAL
| Shipping Dimensions (hwd / in.) | 8.07 x 5.59 x 20.35 |
| Unit Dimensions (hwd / in.) | 5.220 x 18.870 x 2.620 |
| Unit Weight (lbs.) | 5.110 |
FEATURES & SPECIFICATIONS
| Sound Level (Noise) | 42.00 dB |
WARRANTY
| Product Warranty Period (Worldwide) | 2-year limited warranty |
