Tripp-Lite P586-003-DVI-V2 3Ft Mini DisplayPort to DVI Active Adapter

Tripp-Lite P586-003-DVI-V2 3Ft Mini DisplayPort to DVI Active Adapter

MSRP: $34.61
$31.99
(You save $2.62 )
SKU:
P586-003-DVI-V2
Shipping:
Calculated at Checkout
In Stock
Available
Before Ordering

Availability and lead times may vary. Request a quote if you need to confirm availability before placing your order.

Family Owned Since 1932
Nationwide Shipping Serving all 50 states
Technical Support Product selection assistance
Project Assistance Quotes and sourcing support

Description

Features

Send High-Quality Mini DisplayPort v1.2 Video Signals to a DVI Display
  • Connects Mini DisplayPort (or Thunderbolt) computer to DVI-enabled monitor, projector or TV
  • Ideal for displaying video on large monitor or digital sign
  • Mini DisplayPort and DVI-D male connectors
  • No separate adapter required
Vibrant, Superior Video Quality
  • Supports HD video resolutions up to 1920 x 1080 (1080p)
  • Converts Single-Mode and Dual-Mode (DP++) Mini DisplayPort output
  • Perfect for use with graphics cards, such as AMD Eyefinity, that don’t output DP++ signals
Superior Materials for Superior Performance
  • Double shielding with foil and braid for maximum EMI/RFI protection
  • Gold-plated connectors and contacts for excellent conductivity
  • Integral strain relief for long life

Package Includes

  • P586-003-DVI-V2 Mini DisplayPort 1.2 to DVI Active Adapter Cable, 3 ft.
RoHS compliant

Specifications

OVERVIEW
UPC Code 037332192004
Product Type Active
Technology DVI; DisplayPort
VIDEO
Max Supported Video Resolution 1920 x 1080 (1080p)
Max Supported Color Depth 12-bit True Color
HDR Support No
Chroma Sub Sampling 4:4:4; 4:2:2
PHYSICAL
Color Black
Material of Construction ABS, PVC
Cable Jacket Rating VW-1
Cable Outer Diameter (OD) 4.8mm
Wire Gauge (AWG) 32
Cable Length (ft.) 3
Cable Length (in.) 36
Shipping Dimensions (hwd / in.) 9.00 x 7.00 x 0.50
Shipping Weight (lbs.) 0.21
ENVIRONMENTAL
Operating Temperature Range 32 to 113 F (0 to 45 C)
Storage Temperature Range 14 to 176 F (-10 to 80 C)
Operating Humidity Range 10 to 85%, Non-Condensing
Storage Humidity Range 5 to 90%, Non-Condensing
CONNECTIONS
Side A - Connector 1 MINI DISPLAYPORT (MALE)
Side B - Connector 1 DVI-D DUAL-LINK (MALE) (WIRED TO DVI-D SINGLE-LINK)
Connector Plating Gold
Contact Plating   Gold
FEATURES & SPECIFICATIONS
Displayport Specification 1.2
HDCP Specification 1.4
STANDARDS & COMPLIANCE
Certifications CE, FCC, RoHS, REACH
WARRANTY
Product Warranty Period (U.S. & Canada) 3-year limited warranty
