Product Overview
Overview
IEC 60512-99-002 Compliant
PoE Certificate Number: 2019-248
UTP Cat6 22-24 AWG solid cable (Requires PoE cable if used in PoE setting)
Features
24-Port Patch Panel Manages and Organizes High-Density Cat5e Network Cabling
This patch panel enables quick, easy cable patching. Just plug Cat5e cables into its 24 front RJ45 ports, and use a 110 or Krone punch-down tool (do not use a 4/5 pair 110 punch-down tool) to terminate color-coded connections in the rear. Both the front and rear connectors are clearly numbered, and the front ports have blank labels to help you identify individual cable runs. The N052-P24 supports EIA/TIA 568A and 568B wiring standards and is compatible with all network applications.
Specifically Designed for Use in Power over Ethernet Plus (PoE+) Applications
This Power over Ethernet patch panel maximizes performance with PoE+ applications. It prevents spark-gap erosion that degrades the plug and jack contacts over time and can affect data and/or power transmission capabilities. The N052-P24 is designed to handle the frequent mating and unmating of surveillance cameras, VoIP phone systems, wireless access points and other PoE and PoE+ devices under electrical load.
Mounts in 1U of Space in Your 19 in. Enclosure or Open Frame Rack
The high-density patch panel supports mounting in 1U of space in EIA-standard 19-inch racks. Included cable ties and a removable cable management bracket help organize your connections, cut down on cord clutter and maintain stable performance.
TAA-Compliant for GSA Schedule Purchases
The N052-P24 is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
Lifetime Warranty
The N052-P24 is backed by a lifetime warranty, ensuring reliability and performance.
Package Includes
- N052-P24 24-Port 1U Rack-Mount Cat5e Patch Panel - PoE+ Compliant
- Cable management bracket
- (8) Cable ties
- Quick Start Guide
Specifications
OVERVIEW
| UPC Code | 037332210418 |
| Product Type | Punchdown |
| Technology | Cat5/5e |
PHYSICAL
| Color | Black |
| Shipping Dimensions (hwd / in.) | 2.70 x 19.30 x 3.00 |
| Shipping Weight (lbs.) | 1.60 |
| Unit Dimensions (hwd / in.) | 1.73 x 18.89 x 4.38 |
ENVIRONMENTAL
| Operating Temperature Range | 14 TO 140 F (-10 TO 60 C) |
| Storage Temperature Range | -40 TO 154.4 F (-40 TO 68 C) |
| Relative Humidity | 10% TO 90% RH, NON-CONDENSING |
CONNECTIONS
| Number of Ports | 24 |
| PoE Power Budget (Watts) | 90 |
| Side A - Connector 1 | 110 IDC |
| Side B - Connector 1 | RJ45 (FEMALE) |
| PoE Type | Type 3 PoE++/UPoE (60W, IEEE 802.3bt) |
STANDARDS & COMPLIANCE
| Certifications | RoHS, UL, CE |
WARRANTY
| Product Warranty Period (Worldwide) | Lifetime limited warranty |
Overview
IEC 60512-99-002 Compliant
PoE Certificate Number: 2019-248
UTP Cat6 22-24 AWG solid cable (Requires PoE cable if used in PoE setting)
Features
24-Port Patch Panel Manages and Organizes High-Density Cat5e Network Cabling
This patch panel enables quick, easy cable patching. Just plug Cat5e cables into its 24 front RJ45 ports, and use a 110 or Krone punch-down tool (do not use a 4/5 pair 110 punch-down tool) to terminate color-coded connections in the rear. Both the front and rear connectors are clearly numbered, and the front ports have blank labels to help you identify individual cable runs. The N052-P24 supports EIA/TIA 568A and 568B wiring standards and is compatible with all network applications.
Specifically Designed for Use in Power over Ethernet Plus (PoE+) Applications
This Power over Ethernet patch panel maximizes performance with PoE+ applications. It prevents spark-gap erosion that degrades the plug and jack contacts over time and can affect data and/or power transmission capabilities. The N052-P24 is designed to handle the frequent mating and unmating of surveillance cameras, VoIP phone systems, wireless access points and other PoE and PoE+ devices under electrical load.
Mounts in 1U of Space in Your 19 in. Enclosure or Open Frame Rack
The high-density patch panel supports mounting in 1U of space in EIA-standard 19-inch racks. Included cable ties and a removable cable management bracket help organize your connections, cut down on cord clutter and maintain stable performance.
TAA-Compliant for GSA Schedule Purchases
The N052-P24 is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
Lifetime Warranty
The N052-P24 is backed by a lifetime warranty, ensuring reliability and performance.
Package Includes
- N052-P24 24-Port 1U Rack-Mount Cat5e Patch Panel - PoE+ Compliant
- Cable management bracket
- (8) Cable ties
- Quick Start Guide
Specifications
OVERVIEW
| UPC Code | 037332210418 |
| Product Type | Punchdown |
| Technology | Cat5/5e |
PHYSICAL
| Color | Black |
| Shipping Dimensions (hwd / in.) | 2.70 x 19.30 x 3.00 |
| Shipping Weight (lbs.) | 1.60 |
| Unit Dimensions (hwd / in.) | 1.73 x 18.89 x 4.38 |
ENVIRONMENTAL
| Operating Temperature Range | 14 TO 140 F (-10 TO 60 C) |
| Storage Temperature Range | -40 TO 154.4 F (-40 TO 68 C) |
| Relative Humidity | 10% TO 90% RH, NON-CONDENSING |
CONNECTIONS
| Number of Ports | 24 |
| PoE Power Budget (Watts) | 90 |
| Side A - Connector 1 | 110 IDC |
| Side B - Connector 1 | RJ45 (FEMALE) |
| PoE Type | Type 3 PoE++/UPoE (60W, IEEE 802.3bt) |
STANDARDS & COMPLIANCE
| Certifications | RoHS, UL, CE |
WARRANTY
| Product Warranty Period (Worldwide) | Lifetime limited warranty |
