Product Overview
Features
Universal Wall-Mount Bracket Secures and Organizes Your Wireless Access Point
Protect your indoor Wi-Fi access point by mounting it high on a wall or ceiling, away from probing hands. This SmartRack® wall bracket is constructed from heavy-duty cold-rolled steel with a durable white powder-coated finish. It’s recommended for offices, dorms, hotels, classrooms, small businesses and other indoor areas where you need to keep your WAP secure, organized and out of the way.
Accommodates a Wide Range of WAPs, Including Cisco and Aruba
The ENBRKTCVR fits most access-point bolt patterns and is compatible with Cisco low-profile and universal brackets. It also comes with a T-bar bracket for mounting Aruba and other WAP brands. Hardware is included for equipment installation. Open rear and side cutouts allow easy cable routing and reduce cable clutter. The durable wall bracket comes ready for horizontal or vertical mounting on a wall or ceiling with user-provided hardware.
Locks Securely to Help Prevent Damage, Tampering or Theft
This Wi-Fi access point enclosure features a protective steel cover. It locks securely with the included key to protect its contents against theft, tampering, dust and other contaminants.
Package Includes
- Wall bracket with cover
- T-bar bracket
- (4) #8-32 screws
- (2) #6-32 screws
- Cable tie
- Key
- Installation guide
Specifications
OVERVIEW
| UPC Code | 037332214454 |
| Rack Type | Open-Frame |
PHYSICAL
| Color | White |
| Maximum Device Depth (in.) | 9.00 |
| Maximum Weight Capacity (lbs.) | 10 |
| Rack Height | 0U |
| Shipping Dimensions (hwd / in.) | 7.67 x 9.44 x 11.41 |
| Shipping Weight (lbs.) | 4.62 |
| Unit Dimensions (hwd / in.) | 5.050 x 7.378 x 9.087 |
| Unit Dimensions (in.) | 5.1 x 7.4 |
| Unit Weight (lbs.) | 3.100 |
STANDARDS & COMPLIANCE
| Approvals | RoHS |
WARRANTY
| Product Warranty Period (Worldwide) | 5-year limited warranty |
