Tripp-Lite B140-1A1-WP DVI over Cat5 Active Extender Wallplate Kit

$148.99
SKU:
B140-1A1-WP
Shipping:
Calculated at Checkout
Tripp-Lite B140-1A1-WP DVI over Cat5 Active Extender Wallplate Kit

Product Overview

Features

  • 2 piece kit includes both local transmitter and remote receiver wallplates
  • Extend a DVI-D Single-Link signal up to 200 ft. at 1024 x 768 (60Hz), or up to 150 ft. at 1920 x 1200 (60Hz), when using 24Awg, solid wire Cat56 cabling. (Tripp Lite N202 Series Patch Cables)
  • Built in equalization control for the sharp display quality
  • Easy RJ45 patch cable connections
  • No software or drivers required
  • HDCP and DDC compatible
  • Compatible with all operating systems
  • Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

System Requirements

  • DVI Video card and DVI Monitor

Package Includes

  • B140-1A1-WP Local Wallplate
  • B140-1A1-WP Remote Wallplate
  • (2) External Power Supplies with NEMA 1-15P Plug (Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A)
  • Wallplate screws
  • Screwdriver for Equalization adjustment
TAA compliant RoHS compliant

Specifications

OVERVIEW
UPC Code 037332168092
Product Type Extender Kit
Technology DVI; Cat5/5e; Cat6
VIDEO
Max Supported Video Resolution 1920x1080 (1080p @ 60Hz)
Max 720P Range (ft) 200
Max 1080P Range (ft) 150
Max 1280 x 720 (720p) Range (ft) 150
Max 1920 x 1080 (1080p) Range (ft) 150
Transmitter Video Input DVI-I
Transmitter - Number of Video Outputs 1
Receiver/Transceiver Video Output DVI-I
Receiver - Number of Video Outputs 1
Range Extension using other Tripp Lite product 175ft @ 1024 x 768 XGA 125ft @ 1920 x 1080 UXGA
Recommended Cabling N202-Series Cat6 Patch Cable
Other Tripp Lite product used to extend range B140-110
HDR Support No
3D Video Supported Yes
Maximum Signal Range (ft) 200
Maximum Signal Range Details
200 ft @ 1024 x 768 XGA
150 ft @ 1920 x 1080 UXGA
POWER
Power Source Type AC Adapter
AC Plug Type NEMA 1-15P
Power Source Transmitter and Receiver (Included)
Power Over Cable (PoC) Support No
AC Adapter Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A
External Power Supply Input Specs (V / Hz / A) 100-240V / 50-60Hz / 0.5A
External Power Supply Output Specs (V / A) 5V/2A
External Power Supply Cord Length (ft.) 4.5
External Power Supply Cord Length (m.) 1.4
DC Barrel Plug OD: 5.5 x 2.1 x 7.5mm, Positive Pin, Negative Sleeve
USER INTERFACE, ALERTS & CONTROLS
LED Indicators TX & RX: Power (Green); Activity (Orange)
PHYSICAL
Color White
Number of Displays 1
Form Factor/Mounting Options Wallplate
Receiver Unit Dimensions (hwd / in.) 4.5 x 2.75 x 1
Receiver Unit Weight (lbs.) 0.57
Shipping Dimensions (hwd / in.) 2.20 x 6.20 x 8.40
Shipping Weight (lbs.) 1.20
Transmitter Unit Dimensions (hwd / in.) 4.5 x 2.75 x 1
Transmitter Unit Weight (lbs.) 0.57
Unit Packaging Type Box
Housing Plastic
ENVIRONMENTAL
Operating Temperature Range 32 to 104 °F (0 to 40 °C)
Storage Temperature Range 5 to 122 °F (-15 to 50 °C)
Relative Humidity 0% to 85%, Non-Condensing
COMMUNICATIONS
Max 1024 x 768 Range (ft) 200
Max 480P Range (ft) 200
Max 1440 x 900 Range (ft) 200
Max 1080i Range (ft) 150
Max 480i Range (ft) 200
Max 640 x 480 Range (ft) 200
Max 800 x 600 Range (ft) 200
Max 1600 x 1200 Range (ft) 200
EDID Compatible   Yes
IR Remote Extension Support No
RS-232 Serial Extension Support No
Consumer Electronics Control (CEC) Supported Yes
USB Extension Support No
CONNECTIONS
Number of Ports 1
Side A - Connector 1 DVI-I DUAL-LINK (FEMALE) (WIRED TO DVI-D SINGLE-LINK)
Side A - Connector 2 RJ45 (FEMALE)
Side B - Connector 1 DVI-I DUAL-LINK (FEMALE) (WIRED TO DVI-D SINGLE-LINK)
Side B - Connector 2 RJ45 (FEMALE)
FEATURES & SPECIFICATIONS
Driver Required No
10/100 Ethernet Extension Support No
Built-In Equalizer Yes
STANDARDS & COMPLIANCE
Certifications Tested to FCC, RoHS, REACH
External Power Supply Certifications FCC; PSE; TUV; UL; cUL
WARRANTY
Product Warranty Period (Worldwide) 1-year limited warranty
