Splitter Ideal for Digital Signage or Displaying Video in Schools or Trade Show Booths
This four-port transmitter/splitter is recommended for video presentations in conference rooms, schools, trade shows, meeting facilities, houses of worship, retail settings and other digital signage applications where the source and display are farther apart than conventional A/V cables allow. The B127-004-H extends 4K video and stereo audio signals from an HDMI source device to four HDMI displays up to 125 feet (38 meters) away via user-supplied Cat6 cabling.
Transmits Crystal-Clear 4K HDMI Video with Multi-Channel Audio and 4:4:4 Color
The B127-004-H supports Ultra HD video resolutions up to 4K x 2K (3840 x 2160) at 60 Hz, as specified in HDMI 2.0, with full, rich uncompressed DTS-HD, Dolby TrueHD and 7.1-channel digital audio. This transmitter carries HDR signals, which provide a wide range of vibrant colors with richer contrast, brighter whites and deeper blacks. HDCP 2.2 compliance allows you to stream iTunes and Netflix content with no complications. This unit supports 4:4:4 chroma subsampling for top-level PC gaming or using your HDTV as a PC monitor.
Built-In PoC Technology Provides Power to Avoid Bulky External Power Bricks
Built-in Power over Cable (PoC) technology powers the connected B127-100-H or B127-100-H-SR receiver over Cat6 cable. Green and orange LEDs will light up to indicate the unit is receiving power and a signal is being received. PoC lets you avoid the hassle of a bulky power brick and gives you the freedom to transfer power to the remote receivers and place them away from an AC outlet.
Daisy-Chain Multiple Transmitters to Add More Displays
An HDMI output is included for connecting up to three additional B127-004-H transmitters, each of which splits the original HDMI signal into four. You can also connect an optional display to monitor the image connected to the receivers up to 125 feet away.
Plug-and-Play Operation for Quick Setup and Immediate Use
The included transmitter works right out of the box with no software required. Mounting hardware is included for installing the unit on a wall, pole or 19-inch rack. Connect the transmitter to the source with a user-supplied HDMI cable (such as Tripp Lite's P568- or P569-Series). Then, connect the transmitter to Tripp Lite B127-100-H or B127-100-H-SR remote receivers using Cat6 patch cable (such as Tripp Lite N202-Series cable).
TAA-Compliant for GSA Schedule Purchases
The B127-004-H is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
System Requirements
- Source device with HDMI output (Blu-ray player, cable box, laptop)
- Tripp Lite B127-100-H or B127-100-H-SR remote receivers
Package Includes
- Transmitter unit
- External power supply with 4.5 ft. cord (Input: 100-240V, 50/60 Hz, 1.5A; Output: 24V 2A)
- (4) International plug adapters (North America, Europe, U.K. and Australia)
- Mounting hardware
- Owner's manual
Specifications
OVERVIEW
| UPC Code | 037332239044 |
| Product Type | Transceiver |
| Technology | HDMI; Cat5/5e; Cat6; POC |
VIDEO
| Video Input | HDMI (FEMALE) |
| Video Output | HDMI (FEMALE) |
| Max Supported Video Resolution | 3840x2160 (4K @ 60Hz) |
| Max 1280 x 720 (720p) Range (ft) | 200 |
| Max 1920 x 1080 (1080p) Range (ft) | 200 |
| Max 1920 x 1200 Range (ft) | 150 |
| Max 2560 x 1600 Range (ft) | 150 |
| Max 3840 x 2160 (4K@30Hz) Range (ft) | 150 |
| Max 3840 x 2160 (4K@60Hz) Range (ft) | 125 |
| Transmitter Video Input | HDMI |
| Transmitter - Number of Video Outputs | 4 |
| Transmitter - Local Display Output | HDMI |
| Recommended Cabling | Solid Wire Cat6 Cables (Tripp Lite's N202-Series) |
| Max Supported Color Depth | 24-bit True Color |
| HDR Support | Yes |
| 3D Video Supported | Yes |
| Chroma Sub Sampling | 4:4:4 |
| Maximum Signal Range (ft) | 125 |
AUDIO
| Audio Input | HDMI |
| Audio Specification | 7.1 Channel Surround Sound, DTS-HD and Dolby TrueHD |
POWER
| Power Source Type | AC Adapter |
| AC Plug Type | NEMA 1-15P; BS1363; CEE 7/16 Schuko; AS/NZS 3112 |
| Power Source | Transmitter end only (Included) |
| Power Over Cable (PoC) Support | Yes |
| External Power Supply Input Specs (V / Hz / A) | 100-240V / 50-60Hz / 1.5A |
| External Power Supply Output Specs (V / A) | 24V/2A |
| External Power Supply Cord Length (ft.) | 4.5 |
| External Power Supply Cord Length (m.) | 1.37 |
USER INTERFACE, ALERTS & CONTROLS
| LED Indicators | Tx: x1 Green (Power), x6 Orange (Local, 1,2,3,4 Output, Input); Tx RJ45 port: x4 Green (Connected), x4 Orange (Activity) |
PHYSICAL
| Material of Construction | Metal |
| Color | Black |
| Included Mounting Accessories | Wallmount |
| Number of Displays | 4 |
| Form Factor/Mounting Options | Box; Wall-mount |
| Rackmountable | Yes |
| Shipping Dimensions (hwd / in.) | 2.40 x 6.30 x 13.60 |
| Shipping Weight (lbs.) | 2.50 |
| Unit Dimensions (hwd / in.) | 1.17 x 9.25 x 3.94 |
| Unit Packaging Type | Box |
| Unit Weight (lbs.) | 0.65 |
| Housing | Metal |
ENVIRONMENTAL
| Operating Temperature Range | 32 to 104 °F (0 to 40 °C) |
| Storage Temperature Range | 5 to 122 °F (-13 to 50 °C) |
| Relative Humidity | 0% to 85% RH, Non-Condensing |
COMMUNICATIONS
| Signal Range (ft.) | 125 |
| EDID Compatible | Yes |
| IR Remote Extension Support | No |
| RS-232 Serial Extension Support | No |
| Consumer Electronics Control (CEC) Supported | Yes |
| USB Extension Support | No |
CONNECTIONS
| Number of Ports | 4 |
| Side A - Connector 1 | (2) HDMI (FEMALE) |
| Side B - Connector 1 | (4) RJ45 (FEMALE) |
FEATURES & SPECIFICATIONS
| HDCP Specification | 2.2 |
| Driver Required | No |
| Recommended Category Cable | Solid Wire Cat6 Cables (Tripp Lite's N202-Series) |
| 10/100 Ethernet Extension Support | No |
| Built-In Equalizer | Yes |
STANDARDS & COMPLIANCE
| Certifications | Tested to CE, FCC, REACH, RoHS |
| External Power Supply Certifications | CCC; CE; FCC; GS; PSE; TUV; UL; cUL |
WARRANTY
| Product Warranty Period (Worldwide) | 1-year limited warranty |
